Murata SMD 0402 Surface Mount Ferrite Bead 10 Ω Impedance at 100 MHz BLM15AG100SN1D

Name: Murata SMD 0402 Surface Mount Ferrite Bead 10 Ω Impedance at 100 MHz BLM15AG100SN1D
Brand: Murata
SKU: 383119
Price: 0.01 USD
Availability: InStock



Category Ferrite Bead Brand Murata Condition New

Specifications

Country of Origin	India
Brand	Murata
Material	Ferrite
Height	0.5mm
Length	1mm
Model	BLM15AG100SN1D
Depth	0.5mm
Packaging	Tape & Reel
Mount Type	Surface
Current Rating	1A
Series	BLM15
Maximum Operating Temperature	125°C
Package Type	0402
Sub Type	Ferrite Bead
Minimum Operating Temperature	-55°C
Standards/Approvals	RoHS, REACH
Maximum DC Resistance	0.05Ω
Impedance at 100 MHz	10Ω

Key Features

Provides stable noise suppression performance across 30 MHz to several hundred MHz.
Features a tape and reel packaging suitable for automated insertion.
Supports a current rating of 1A for reliable circuit protection.
Boasts low maximum DC resistance of 0.05 Ω ensuring minimal signal loss.
Operates reliably within a temperature range of -55°C to 125°C.
Constructed with ferrite material offering excellent EMI filtering properties.
Compact 0402 package size with dimensions 1 mm length x 0.5 mm height x 0.5 mm depth.
Nickel barrier external electrodes provide excellent solder heat resistance.

Product Description

Murata BLM15AG100SN1D is a surface mount device (SMD) ferrite bead in the compact 0402 package designed to suppress high-frequency noise and electromagnetic interference (EMI) in electronic circuits. With an impedance of 10 Ω at 100 MHz, it efficiently attenuates unwanted signals without distorting waveform integrity, making it ideal for use in communications, power supply, and general-purpose electronic applications.

The device supports a current rating of 1 ampere and features a very low maximum DC resistance of 0.05 Ω, which minimizes power loss and heat generation within circuits. The bead operates reliably in harsh environments over a wide temperature span from -55°C up to 125°C, providing durability and stability for industrial and automotive electronics. Its nickel barrier external electrodes enhance solderability and thermal endurance during assembly.

Packaged in tape & reel format, the BLM15AG100SN1D is optimized for high-volume automated pick-and-place manufacturing, supporting efficient production workflows. The use of specialized ferrite material ensures consistent noise suppression across a broad frequency range starting from 30 MHz upwards. This product complies with RoHS and REACH standards, affirming its adherence to environmental and safety regulations.

Applications include EMI noise reduction for sensitive signal lines and power lines in industrial machines, consumer electronics, and communication devices. Its low profile and small form factor make it suitable for space-constrained PCB designs where effective EMI filtering is required without additional grounding elements.

Stable noise suppression from 30 MHz to several hundred MHz. Tape & reel packaging format for automated assembly. Rated for 1 ampere current carrying capacity. Low maximum DC resistance of 0.05 ohms. Operating temperature range: -55°C to 125°C.

Ferrite material construction for EMI filtering. Dimensions: 1 mm length, 0.5 mm height, 0.5 mm depth. Nickel barrier external electrodes for solder heat resistance. RoHS and REACH compliant.
