Carlo Gavazzi Monitoring Relay 1 Phase SPDT DIN Rail 115V AC, 230V AC DIB01CB235A

Carlo Gavazzi DIB01CB235A monitoring relay is a high-quality industrial device designed for single-phase over voltage and over current monitoring. This model is equipped with a Single Pole Double Throw (SPDT) contact and mounts easily on standard DIN rails, making it ideal for control panels and electrical automation systems.

The relay operates on supply voltages of both 115 V AC and 230 V AC, allowing for broad compatibility in various electrical environments. It includes a current sensitivity feature capable of detecting undercurrent and overcurrent conditions and selectable measuring ranges via DIP switches, ranging from 2 to 20 VAC/DC and 5 to 50 VAC/DC, enhancing its adaptability in monitoring applications.

A key feature is its 8 A SPDT relay output, which is normally de-energized, providing reliable switching performance. The built-in latch function maintains the relay's ON position when tripped, with a red LED indicator clearly signaling alarm status, which facilitates easy troubleshooting and maintenance.

Designed with user convenience in mind, this monitoring relay features screw terminal connections and an IP20 protection rating suitable for protected indoor environments. Its compact dimensions - 99.5 mm length, 80 mm height, and 22.5 mm width - allow efficient use of panel space.

This product complies with multiple industrial standards including IEC 60947, RoHS, EN 61000-6-3, CE, and UL EN 61000-6-2, ensuring it meets rigorous safety and performance benchmarks. Manufactured in Italy, it combines European quality craftsmanship with advanced functionality.

Ideal for industrial, manufacturing, electrical automation, and process control applications, this Carlo Gavazzi monitoring relay provides reliable protection and monitoring for your electrical systems.

Equipped with 8 A SPDT relay output normally de-energized for reliable operation. Wide supply voltage compatibility of 115 V AC and 230 V AC for flexible installation. Durable design including IP20 rating and screw terminal connections.

Adjustable measuring ranges from 2 to 20 VAC/DC and 5 to 50 VAC/DC for versatile monitoring. Built-in latch function maintains relay state with clear red LED alarm indication. Complies with IEC 60947, RoHS, EN 61000-6-3, CE, and UL EN 61000-6-2 standards.

Compact form factor with dimensions 99.5 mm length, 80 mm height, and 22.5 mm width. Suitable for industrial electrical automation, monitoring, and protection applications. Manufactured in Italy ensuring quality and reliability.
