SMC Pneumatic Solenoid Valve 3/2 NC Solenoid G 1/8 Threaded Port 24V DC Die Cast Aluminium VT307Y-5DO1-01F-Q

Free Delivery in India | Lowest Global Shipping Charges

SMC Pneumatic Solenoid Valve 3/2 NC Solenoid G 1/8 Threaded Port 24V DC Die Cast Aluminium VT307Y-5DO1-01F-Q



Category Pneumatic Solenoid Valves Brand SMC Condition New

Specifications

Country of Origin	Japan
Voltage	24V dc
Brand	SMC
Body Material	Die Cast Aluminium
Maximum Operating Pressure	0.7 Mpa
Height	84mm
Length	77.6mm
Model	VT307Y-5DO1-01F-Q
Width	25.6mm
Mount Type	Manifold
Series	VT
Number Of Ports	3
Maximum Operating Temperature	50°C
Port Type	Threaded
Number of Positions	3
Port Size	1/8 in
Seal Material	Hydrogenated Nitrile Rubber
Minimum Operating Temperature	-10°C
Actuation Type	Solenoid
Maximum Flow Rate	177L/min
Standards/Approvals	CE, RoHS
Connection Thread Standard	G 1/8
Mount Pattern	DIN
Minimum Pilot Pressure	0MPa
Valve Function	3/2 NC
Electrical Connection Type	DIN Connector
Maximum Pilot Pressure	1MPa
Solenoid Type	Single
Port Gender	Female
Solenoid Power Consumption	4.2W
Various functions	N/O, N/C, Divider valve, Selector valve

Key Features

The valve features a manifold mount type with a die cast aluminium body.
It has 3 ports and 3 positions for versatile pneumatic functions.
Operates reliably within a maximum pressure of 0.7 Mpa and maximum temperature of 50°C.
Seal material is hydrogenated nitrile rubber ensuring durability and leak resistance.
The valve includes a DIN connector with IP65 protection for electrical ingress safety.
Compact dimensions include 84 mm height, 77.6 mm length, and 25.6 mm width.
Power consumption is low at 4.2 W, offering energy-efficient operation.
Suitable for varied industrial applications such as blow-off valves, pressure release, and cylinder drives.

Product Description

SMC VT307Y-5DO1-01F-Q Pneumatic Solenoid Valve 3/2 NC, with G 1/8 threaded port and 24V DC voltage, is engineered for precise control in pneumatic systems used in industrial automation and fluid power applications.

This valve belongs to the VT series direct-acting solenoid valves, notable for its reduced power consumption and versatility in varied settings including blower valves, pressure release valves, and single or double-acting cylinder drives.

Constructed with a die cast aluminium body, the valve offers robust durability and is manifold mounted with a DIN pattern for easy integration. The seal material, hydrogenated nitrile rubber, enhances reliability by providing effective sealing under pressure up to 0.7 Mpa and temperatures up to 50°C.

Electrical connection is established via a DIN connector featuring IP65 protection, suitable for harsh industrial environments. The device supports a range of functions including normally open, normally closed, divider, and selector valve configurations, easily toggled by function plate inversion.

The valve's compact size and three-port design enable diverse application scenarios in manufacturing, automation, HVAC systems, and laboratory equipment. Engineered to operate from -10°C to 50°C, eligible for use across different working environments.

Supports maximum pilot pressure of 1 MPa, minimum 0 MPa, and consumes only 4.2 W power. Approved to CE and RoHS standards, ensuring compliance with international quality and environmental regulations.

Originating from Japan, this valve is a reliable component for professionals requiring efficient pneumatic control solutions. Its design allows unrestricted mounting orientation with non-locking manual override for operational flexibility.
