Carlo Gavazzi 1 Phase SPDT DIN Rail Monitoring Relay 115V AC, 230V AC, 48V AC DUB01CB23500V

Carlo Gavazzi DUB01CB23500V is a high-quality 1 Phase SPDT Monitoring Relay designed for precise over voltage and over current monitoring in industrial electrical applications. It supports a variety of AC and DC supply voltages including 48 V AC, 115 V AC, and 230 V AC, making it highly versatile for different system requirements.

This relay features selectable measuring ranges via DIP switches, accommodating voltage ranges from 2 to 20 VAC/DC up to 50 to 500 VAC/DC. It includes programmable latching at set points to maintain alarm status, indicated by a bright red LED for immediate visual feedback.

The device mounts easily on DIN rails with a compact footprint of 99.5 mm length, 22.5 mm width, and 80 mm height. It is rated IP20 for protection against solid objects, and utilizes screw terminals for secure electrical connections. The relay output is an 8 A SPDT contact type which is normally de-energized to enhance operational safety.

Operating temperature ranges from -60°C to +60°C allow for deployment in challenging environments. Compliance with internationally recognized standards such as IEC 60947, EN 61000-6-3, CE, UL EN 61000-6-2, and RoHS ensures reliability and environmental compliance.

Suitable for single-phase electrical systems with SPDT contact configuration. Adjustable measuring ranges from 2 to 500 VAC/DC via DIP-switches. 8 A SPDT relay output normally de-energized for safety. LED indication for relay status and power supply.

Compact DIN rail mounting with IP20 protection. Wide operating temperature capability from -60°C to +60°C. Galvanically separated power supply for enhanced safety. Complies with IEC 60947, EN 61000-6-3, CE, UL EN 61000-6-2, and RoHS standards.

This monitoring relay is ideal for industrial automation, electrical panel monitoring, HVAC control systems, manufacturing process safety, and other commercial applications requiring voltage and current monitoring. It enables enhanced system protection by triggering alarms or control actions during abnormal voltage or current conditions.

Carlo Gavazzi's DUB01 series monitoring relays deliver dependable performance, ease of installation, and flexible configuration options, supporting operational efficiency and equipment protection.
