Eaton xEffect Miniature Circuit Breaker, 3-Pole, 25A, Type D, 415V AC, 10 kA Breaking Capacity 278898 FAZ-D25/3

Free Delivery in India | Lowest Global Shipping Charges

Eaton xEffect Miniature Circuit Breaker, 3-Pole, 25A, Type D, 415V AC, 10 kA Breaking Capacity 278898 FAZ-D25/3

Name: Eaton xEffect Miniature Circuit Breaker, 3-Pole, 25A, Type D, 415V AC, 10 kA Breaking Capacity 278898 FAZ-D25/3
Brand: Eaton
SKU: 381417
Price: 140.81 USD
Availability: InStock



Category Miniature Circuit Breaker Brand Eaton Condition New

Specifications

Country of Origin	India
Range	xEffect
Brand	Eaton
Model	278898 FAZ-D25/3
Depth	73mm
IP Rating	IP20
Width	85mm
Mount Type	DIN Rail
Current Rating	25A
Series	xEffect
Terminal type	Twin-Purpose Terminal
Breaking Capacity	10kA
Number of Poles	3
Rated AC Voltage	415V ac
Tripping Characteristics	Type D
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Toggle Switch
Break Time	Instantaneous
Cooper Bussmann 6A Cartridge Fuse, 6.3 x 32mmBrand	Cooper Bussmann

Key Features

This circuit breaker is rated for 25 amperes of current and supports 3-pole operation for three-phase systems.
It features a Type D tripping characteristic suitable for high inrush current applications.
The device operates at a rated AC voltage of 415 volts and has a breaking capacity of 10 kiloamperes.
Mounting is designed for standard DIN rail installation, ensuring ease of assembly.
The toggle switch actuator can be sealed in both on and off positions for safety compliance.
It incorporates thermal magnetic tripping mechanisms to provide six levels of overcurrent protection.
The breaking time is instantaneous, delivering quick response to faults.
The terminal type is twin-purpose, facilitating flexible wiring options.

Product Description

Eaton 278898 FAZ-D25/3 Miniature Circuit Breaker is engineered for industrial and commercial electrical applications requiring reliable and safe circuit protection. It supports a 3-pole configuration suitable for three-phase power systems with a current rating of 25 amperes, making it ideal for motor and control panel protection.

The Type D tripping characteristic ensures the breaker can handle devices with high inrush currents such as motors and transformers without nuisance tripping. This model operates at a rated AC voltage of 415V and offers a robust breaking capacity of 10 kA, which effectively interrupts short circuits and protects equipment.

Designed for DIN rail mounting, it allows straightforward installation in standard electrical frameworks.

The toggle switch actuator supports sealing in on or off positions to prevent accidental operation, while the trip-free design ensures safety by preventing manual bypass of the protective function.

This miniature circuit breaker has a current limiting design that reduces energy let-through during short circuits. It employs a thermal magnetic tripping mechanism providing six levels of overcurrent protection for precise operation.

Clear red or green indication signals the contact status for easy diagnostics. Its twin-purpose terminals accept multiple wiring configurations, enhancing installation flexibility. An IP20 rating offers protection against solid object ingress, suitable for indoor electrical panels.

Compact dimensions of 85mm width and 73mm depth optimize panel space. This product is commonly used in industrial, manufacturing, HVAC, water treatment, and commercial electrical systems requiring dependable protective devices.
