TDK Shielded Surface Mount Inductor Metallic Magnetic Core 1 μH ±20% 5.9A Idc SPM5012T-1R0M

TDK SPM5012T-1R0M is a shielded surface mount inductor engineered with a metallic magnetic core, offering an inductance of 1 μH with ±20% tolerance. This component is specifically designed for power circuit applications requiring high current capability with minimal electromagnetic interference.

The inductor is housed in a compact 5012 package with dimensions of 5.4 mm length, 5.1 mm depth, and a low profile height of 1.2 mm, favoring space-efficient PCB layouts. Magnetic shielding reduces hum noise compared to core adhesive coil types, providing improved performance stability especially in sensitive circuits.

Its wirewound construction and molded coil provide mechanical robustness and durability. Rated to operate between -40°C and 125°C, this inductor sustains performance across harsh industrial environments. The low DC resistance of 44 mΩ ensures minimized power loss for energy-efficient designs.

This product is RoHS compliant, supporting environmentally responsible manufacturing. It's delivered in tape and reel packaging, optimized for automated surface mount technology assembly lines, enhancing production efficiency.

Applications include industrial electronics, power supplies, automotive electronics (non-automotive standard), telecommunications, and other commercial or manufacturing equipment requiring reliable inductors with compact sizing and high current handling.

This inductor features a 5012 package case with low-profile height of 1.2mm and compact dimensions. It is magnetically shielded to reduce electromagnetic interference in power circuit applications. Constructed with a molded wirewound coil over a metallic magnetic core for enhanced performance.

Rated for a maximum operating temperature of 125°C and minimum of -40°C for reliable operation. Has low DC resistance of 44mΩ ensuring energy efficiency and minimizing losses. Comes in tape and reel packaging suitable for automatic assembly processes.

Designed to meet RoHS compliance for environmental safety. Termination via solder style ensures solid electrical and mechanical connection. Explore more Surface Mount Inductors from TDK at EnvMart for industrial and commercial electronic component needs.
