Bourns 4026 Shielded Wirewound Surface Mount Inductor, 220 μH ±20 %, 200 mA, Ferrite Core SRN4026
Specifications
| Country of Origin | India |
|---|---|
| Brand | Bourns |
| Height | 2.5mm |
| Length | 4mm |
| Model | SRN4026 |
| Depth | 4mm |
| Packaging | Reel |
| Series | SRN4026 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance Range | 1 to 220 μH |
| Inductance | 220μH |
| Standards/Approvals | RoHS |
| Package/Case | 4026 |
| Maximum DC Current | 200mA |
| Pin Count | 2 |
| Maximum DC Resistance | 2.76Ω |
| Inductance Tolerance | ±20 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 4MHz |
| Minimum Quality Factor | 30 |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Constructed with a ferrite core providing semi-shielded wirewound design.
- Compact dimensions of 4 mm length, 2.5 mm height, and 4 mm depth.
- Rated for operation from -40°C to 125°C operating temperature range.
- Features solder termination style and comes in a reel packaging.
- Complies with AEC-Q200 automotive standard and RoHS directive.
- Maximum DC resistance is 2.76 Ω ensuring efficient performance.
- Designed for use in DC/DC converters, notebook computers, and other electronic devices.
- High quality factor of minimum 30 and maximum self-resonant frequency of 4 MHz.
Product Description
Bourns SRN4026 4026 Shielded Wirewound Surface Mount Inductor is a semi-magnetically shielded power inductor with a ferrite core, providing an inductance value of 220 μH ±20 % at a maximum DC current of 200 mA. This wirewound surface mount inductor is designed for various industrial and electronic applications requiring robust performance in compact sizes.
Measuring 4 mm in length, 2.5 mm in height, and 4 mm in depth with 2 solder termination pins, it is perfectly suited for high-density surface mount technology assemblies. Its ability to operate reliably in a temperature range from -40°C up to 125°C, along with compliance to the AEC-Q200 automotive standard, makes it ideal for automotive and industrial electronic designs.
The inductor’s ferrite core construction offers effective shielding and low electromagnetic interference, with a maximum DC resistance of 2.76 Ω and a minimum quality factor of 30 ensuring high efficiency and performance at frequencies up to 4 MHz.
This component is molded and supplied on reel packaging, enabling seamless automated PCB assembly processes. It finds applications in DC/DC converters, notebook computers, digital video cameras, hard disk drives, cellphones, televisions, and LCD displays, addressing a wide range of industrial, commercial, and consumer electronics needs.
Constructed with a ferrite core providing semi-shielded wirewound design. Compact package of 4026 case size for space-saving on PCB layouts. Wide operating temperature range from -40°C to 125°C for reliability in harsh conditions.
Compliant with RoHS directive ensuring environmental safety. Designed for efficient energy storage and filtering in power electronics.
Explore more Surface Mount Inductors and related components from Bourns and other top brands in the Electronics & Electricals category, perfect for advanced industrial and commercial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 220 μH ±20 %.
It has a maximum DC current rating of 200 mA.
This inductor measures 4 mm in length, 2.5 mm in height, and 4 mm in depth.
The operating temperature range is from -40°C to 125°C.
The maximum DC resistance is 2.76 Ω.
The maximum self-resonant frequency is 4 MHz.
It is constructed with a ferrite core, providing effective shielding and low electromagnetic interference.
The termination style is solder, featuring two solder termination pins.
Yes, it complies with the AEC-Q200 automotive standard and the RoHS directive.
The inductor is molded and supplied on reel packaging, facilitating automated PCB assembly processes.
It has a minimum quality factor of 30, ensuring efficient performance.
