STMicroelectronics Operational Amplifier 900 kHz 5-Pin Surface Mount SOT-23 5.5V TSX561AIYLT

Free Delivery in India | Lowest Global Shipping Charges

STMicroelectronics Operational Amplifier 900 kHz 5-Pin Surface Mount SOT-23 5.5V TSX561AIYLT

Name: STMicroelectronics Operational Amplifier 900 kHz 5-Pin Surface Mount SOT-23 5.5V TSX561AIYLT
Brand: STMicroelectronics
SKU: 379554
Price: 1.93 USD
Availability: InStock



Category Operational Amplifier Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Brand	STMicroelectronics
Height	1.3mm
Length	3mm
Model	TSX561AIYLT
Width	1.75mm
Mount Type	Surface
Series	TSX561A
Output Current	2.5mA
Maximum Operating Temperature	125°C
Package Type	SOT-23
Minimum Operating Temperature	-40°C
Number Of Channels	1
Standards/Approvals	RoHS
Pin Count	5
Automotive Standard	AEC-Q100
Maximum Supply Voltage	5.5V
Minimum Supply Voltage	3V
GBP - Gain Bandwidth Product	900kHz
Input Bias Current	200 pA
Slew Rate	1.1V/μs
ESD high tolerance	4 kV
Gain bandwidth product	900 kHz typical
Wide temperature range	-40°C to +125°C
Low input bias current	1 pA typical

Key Features

Gain bandwidth product of 900 kHz supports accurate signal amplification.
Operating voltage range from 3V to 5.5V for flexible power supply options.
Low input bias current of 200 pA and input offset voltage of 1800 μV ensure precision.
Wide temperature range from -40°C to 125°C for rugged industrial use.
Compact 5-pin SOT-23 package sized 3mm x 1.75mm x 1.3mm for surface mounting.
Meets RoHS compliance and AEC-Q100 automotive standard for quality and reliability.
Output current capability of 2.5 mA with a slew rate of 1.1 V/μs for responsive performance.
High ESD tolerance of 4 kV protects against electrostatic damage in harsh environments.

Product Description

STMicroelectronics TSX561AIYLT operational amplifier is a precision, low power single-channel device with a gain bandwidth of 900 kHz, housed in a compact 5-pin SOT-23 surface mount package. It is engineered to operate over a wide supply voltage range from 3V to 5.5V and supports industrial temperature ranges from -40°C to 125°C, ensuring stable performance in demanding environments.

This operational amplifier is characterized by a low input bias current of 200 pA and an input offset voltage of 1800 μV, providing high accuracy signal amplification. The slew rate of 1.1 V/μs and output current up to 2.5 mA allow for responsive operation in diverse electronic circuits.

Compliance with RoHS standards and AEC-Q100 automotive qualification certify its suitability for automotive industry applications, while the robust 4 kV ESD tolerance improves reliability in industrial environments. The small footprint 3 x 1.75 x 1.3 mm package facilitates easy integration into modern PCB designs, especially where space saving is critical.

The amplifier supports precision analog signal processing in industrial, automotive, and laboratory instrumentation. Low power consumption of approximately 235 μA at 5V operation extends battery life in portable devices.

Its wide temperature range and automotive qualification make it ideal for embedded control systems within vehicles. Applications include sensor signal conditioning, data acquisition systems, and general-purpose amplification needs.

Set includes 1 single-channel TSX561AIYLT Operational Amplifier in SOT-23 package. Explore the extensive range of STMicroelectronics amplifiers and semiconductor components at EnvMart for your precise electronic design requirements.
