MEAN WELL 600W 24V DC Chassis Mount Switching Power Supply HEP-600-24
Specifications
| Country of Origin | China |
|---|---|
| Brand | MEAN WELL |
| Power | 600W |
| Efficiency | 95% |
| Length | 253mm |
| Model | HEP-600-24 |
| Depth | 48.5mm |
| Gross Weight | 3.9kg |
| Width | 127mm |
| Mount Type | Chassis |
| Series | HEP-600 |
| Maximum Operating Temperature | 70°C |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Maximum Input Voltage | 431, 305V dc |
| Protections | Short circuit / Over current / Over voltage/ Over temperature |
| Standards/Approvals | EAC TP TC 004, ASNZS 668.1, TUV BS ENEN 6681, UL 6681 |
| Maximum Output Voltage | 24V dc |
| SMPS Output Current | 25A |
| Minimum Input Voltage | 90V ac |
Key Features
- Provides a reliable maximum output voltage of 24V DC with 25A current.
- Operates efficiently with 95% efficiency and built-in active PFC function.
- Wide input voltage range from 90V AC to 431V DC supports versatile power environments.
- Fan-less design allowing cooling via free air convection from -40°C to +70°C operating temperature.
- Encased in aluminum with silicone potting for durability and waterproofing in harsh conditions.
- Protected against short circuit, over current, over voltage, and over temperature for safety.
- Complies with multiple international standards including EAC TP TC 004, ASNZS 668.1, TUV BS ENEN 6681, and UL 6681.
- Suitable for industrial, telecommunication, signage, and outdoor applications requiring stable DC power.
Product Description
MEAN WELL HEP-600-24 is a robust, high efficiency 600W AC-DC enclosed switch mode power supply designed for industrial and outdoor use. Featuring a 24V DC output voltage and 25A rated current, this chassis mount power supply supports a wide universal AC input range of 90 to 264 Vac and accepts up to 431V DC input voltage. It is engineered for hard environments with its silicone potting and aluminum enclosure providing waterproof and vibration resistance capabilities, making it ideal for telecommunications, signage, industrial automation, and other demanding sectors.
This switch mode power supply achieves up to 95% efficiency and includes built-in active power factor correction (PFC) to improve energy use. The fan-less thermal design enables reliable operation from -40°C to +70°C by natural convection, reducing noise and maintenance needs.
Key protections include short circuit, over current, over voltage, and over temperature safeguards, enhancing system reliability and safety. The unit features an output voltage and current adjustable via an internal potentiometer, providing flexibility in various applications. Its compact form factor and modest 3.9 kg weight allow for convenient integration.
The HEP-600-24 power supply complies with international standards such as EAC TP TC 004, ASNZS 668.1, TUV BS ENEN 6681, and UL 6681. It is a dependable power source for industries requiring consistent, clean, and regulated DC power under challenging environmental conditions.
Reliable maximum output voltage of 24V DC at 25A output current. High efficiency of 95% with built-in active PFC function. Universal AC input range and fan-less convection cooling from -40°C to +70°C. Encased in aluminum and silicone potting for waterproof and vibration resistance.
Protections against short circuit, over current, over voltage, and over temperature. Compact chassis mount design with LED power indicator. Meets multiple global standards ensuring safety and compliance. Ideal for industrial, telecommunication, outdoor signage, and other harsh environment applications.
Explore the range of MEAN WELL Switching Power Supplies at EnvMart for industrial-grade, efficient DC power solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The MEAN WELL HEP-600-24 provides a maximum output voltage of 24V DC with a rated current of 25A.
This power supply operates with an efficiency of up to 95%.
It supports a wide input voltage range from 90V AC to 431V DC.
The dimensions of the HEP-600-24 are 253mm in length, 127mm in width, and 48.5mm in depth, with a gross weight of 3.9kg.
It features protections against short circuit, over current, over voltage, and over temperature.
The unit operates efficiently within a temperature range of -40°C to +70°C.
This model has a fan-less design that allows for cooling via free air convection.
It is designed for chassis mounting.
It complies with multiple standards including EAC TP TC 004, ASNZS 668.1, TUV BS ENEN 6681, and UL 6681.
This power supply is suitable for industrial, telecommunication, signage, and outdoor applications requiring stable DC power.
Yes, the output voltage and current can be adjusted via an internal potentiometer.
It is encased in aluminum and features silicone potting for durability and waterproofing.
