Wurth Elektronik 3.2 V Blue LED 3216 Surface Mount Tape & Reel 105mW Power 145mcd Luminosity WL-SMCW 150120BS75000

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik 3.2 V Blue LED 3216 Surface Mount Tape & Reel 105mW Power 145mcd Luminosity WL-SMCW 150120BS75000

Name: Wurth Elektronik 3.2 V Blue LED 3216 Surface Mount Tape & Reel 105mW Power 145mcd Luminosity WL-SMCW 150120BS75000
Brand: Wurth Elektronik
SKU: 376370
Price: 0.24 USD
Availability: InStock



Category LED Brand Wurth Elektronik Condition New

Specifications

Country of Origin	China
Brand	Wurth Elektronik
Model	150120BS75000
Packaging	Tape & Reel
Mount Type	Surface
Series	WL-SMCW
Maximum forward current	30mA
Viewing angle	140 °
Package Type	3216
Standards/Approvals	RoHS
LED Colour	Blue
Dominant Wavelength	470nm
Forward Voltage	3.2V
Number of Pins	2
LED Luminosity	145 mcd
Maximum Power Dissipation	105mW
Lens Dimensions	3.2 x 1.6 x 0.68 mm
Lens Shape	Rectangular
Industry-standard packages	0603 / 0805 / 1206

Key Features

Features a blue light emission with a forward voltage of 3.2 V.
Maximum forward current rating of 30 mA ensures reliable operation.
Compact 3216 package with surface mount type for efficient PCB integration.
Offers 105 mW maximum power dissipation and a luminous intensity of 145 mcd.
Wide 140 degree viewing angle provides excellent visibility in various lighting conditions.
Constructed with a water-clear rectangular lens measuring 3.2 x 1.6 x 0.68 mm.
RoHS compliant ensuring environmentally friendly manufacturing standards.
Packaged in tape and reel for easy automated assembly processes.

Product Description

Wurth Elektronik 150120BS75000 is a high-quality 3.2 V blue LED in the 3216 surface mount package designed for precision and efficiency in lighting applications. This WL-SMCW series LED features a water-clear rectangular lens that enables high brightness output while maintaining a compact form factor, measuring 3.2 x 1.6 x 0.68 mm.

Rated for a maximum forward current of 30 mA and power dissipation of 105 mW, this LED offers a luminous intensity of 145 millicandela with a dominant wavelength of 470 nm. The wide 140° viewing angle allows for broad visibility, making it ideal for indicator lights, backlighting for mobile and portable devices, message boards, switch and indicator illumination, toys, and general lighting purposes.

The device is surface mounted and supplied in tape and reel packaging to facilitate efficient automated assembly in industrial, commercial, and manufacturing setups. Being RoHS compliant, it supports environmental safety without compromising performance or reliability.

These single colour SMD chip LEDs from the WL-SMCW series deliver high luminous efficacy with low power consumption and long operational lifetimes, suitable for applications in electronics, industrial control systems, and consumer devices.

Blue LED with 3.2 V forward voltage and 30 mA maximum forward current. Surface mount 3216 package with clear rectangular lens. Wide viewing angle of 140 degrees for optimal light dispersion. Power dissipation up to 105 mW ensures reliable performance.

Supplied in tape & reel packaged for automated assembly. RoHS compliant for environmental safety. Applicable for backlighting, indicators, displays, and toys. Explore a wide range of LEDs and electronic components at EnvMart for your industrial, laboratory, manufacturing, and commercial lighting needs.
