TE Connectivity 1812 Shielded Wirewound Surface Mount Inductor 2.2 μH ±10%, 380 mA Idc, Q:50, Ferrite Core 3613C2R2K

TE Connectivity 3613C2R2K is a shielded wirewound Surface Mount Inductor with a ferrite core, offering 2.2 μH inductance with a ±10% tolerance. Designed specifically for automatic mounting applications, it features a compact 1812 package size measuring 4.5 mm in length and 3.2 mm in height and depth.

With a maximum DC current rating of 380 mA and a maximum DC resistance of 700 mΩ, this inductor provides efficient current handling and minimal power loss. It is constructed with a ferrite core and uses a moulded wirewound design, ensuring mechanical reliability and consistent performance in industrial and electronic applications.

The device supports a wide operating temperature range from -30°C to +100°C, making it suitable for various commercial and industrial environments, including electronics manufacturing, power supplies, and signal filtering applications. Its shielding and solder termination style further enhance durability during surface mount assembly and operation.

The 3613C2R2K has a high quality factor (Q) of 50 and a maximum self-resonant frequency of 55 MHz, ensuring good performance at high frequencies typical in power and communication circuits. Compliance with RoHS standards attests to its environmental compatibility.

Constructed with a ferrite core for reliable performance. Maximum DC current rating of 380 mA for efficient operation. Compact 1812 package size suitable for surface mounting. Features shielding and solder termination for enhanced durability.

Temperature range from -30°C to 100°C supports varied industrial environments. Maximum DC resistance of 700 mΩ ensures low power loss. High quality factor of 50 and self-resonant frequency of 55 MHz. RoHS compliant manufacturing meets environmental standards.

Moulded wirewound construction increases robustness. Designed in the 3613C series with 2-pin configuration.

This inductor is ideal for industrial electronics, power management, telecommunications, and manufacturing uses that require stable inductive components. Environmentally conscious engineers will appreciate the RoHS compliance and high durability design.
