onsemi DC Input Phototransistor Output Optocoupler Surface Mount 6-Pin MDIP H11D1SR2M

onsemi H11D1SR2M is a DC input optocoupler featuring a phototransistor output, housed in a surface mount 6-pin MDIP package. It is built for efficient signal isolation in various industrial and electronic applications, including industrial controls, power supplies, and consumer electronics.

This device supports a maximum forward voltage of 1.5V and a DC input current up to 80mA. With typical rise and fall times of 5 microseconds, it offers fast switching suitable for precise signal transmission.

Operating temperature ranges from -40°C to 100°C ensure reliability in harsh environments. The product complies with international safety standards such as EN, UL, and IEC, emphasizing its quality and safety for industrial use.

Available in tape and reel packaging, the H11D1SR2M optocoupler facilitates automated pick-and-place assembly processes. Its single channel and 6-pin MDIP configuration make it compatible with a wide range of printed circuit board designs.

While it is not designed to meet automotive standards, it remains a versatile component for general industrial and electronic equipment requiring optical isolation and noise reduction.

Maximum forward voltage of 1.5V ensures efficient input performance. Maximum input current of 80mA with DC input current type. Fast switching with typical rise and fall times of 5μs. Operational temperature range from -40°C to 100°C.

Compliance with EN, UL, IEC standards for safety. Surface mount 6-pin MDIP package facilitates PCB assembly. Single channel optocoupler suitable for signal isolation. Tape and reel packaging supports automated production.

Suitable for industrial, electronic, and control system applications. Explore a broad range of electronic components including Optocouplers and photodetectors at EnvMart for industrial and electronic manufacturing needs.
