onsemi Receiver IC 2 LVTTL Inputs LVDS Outputs 8-Pin SOIC FIN1028MX

Free Delivery in India | Lowest Global Shipping Charges

onsemi Receiver IC 2 LVTTL Inputs LVDS Outputs 8-Pin SOIC FIN1028MX

Name: onsemi Receiver IC 2 LVTTL Inputs LVDS Outputs 8-Pin SOIC FIN1028MX
Brand: onsemi
SKU: 374563
Price: 0.82 USD
Availability: InStock



Category LVDS Interface Ics Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.5mm
Length	5mm
Model	FIN1028MX
Mount Type	Surface
Output type	LVDS
Series	FIN1028
Input Type	LVTTL
Maximum Operating Temperature	85°C
Package Type	SOIC
Sub Type	Receiver
Minimum Operating Temperature	-40°C
Pin Count	8
Number of Elements per Chip	2
Maximum Supply Voltage	3.6V
Minimum Supply Voltage	3V
Number of Drivers	2
Number of Receivers	2
Transmission Data Rate	400Mbps
Differential Input High Threshold Voltage	100mV
Differential Input Low Threshold Voltage	-100mV

Key Features

Supports low voltage differential signaling (LVDS) for high-speed communication.
Includes 2 receivers and 2 drivers on a single chip.
Operates with a minimum supply voltage of 3V up to maximum 3.6V.
Transmission data rate up to 400 Mbps for efficient data handling.
Equipped with ESD protection for enhanced device reliability.
Compact 8-pin SOIC surface mount package ensures easy PCB integration.
Designed to operate in extended temperature range from -40°C to 85°C for industrial environments.
Differential input high and low threshold voltages are 100mV and -100mV respectively.

Product Description

onsemi FIN1028MX is a highly reliable Receiver IC featuring 2 LVTTL inputs and 2 LVDS outputs, housed in an 8-Pin SOIC surface mount package. It supports low voltage differential signaling (LVDS) which enables robust high-speed data transmission of up to 400 Mbps, making it ideal for applications demanding high bandwidth and noise immunity.

The device includes two drivers and two receivers integrated per chip, optimized for use in communication interfaces such as Firewire, SATA, and SCSI. It operates on a supply voltage range from 3V to 3.6V and supports wide operating temperatures from -40°C to 85°C, suitable for demanding industrial environments.

The FIN1028MX is built with ESD protection to enhance the reliability of the device in harsh electrical environments. Its compact 8-pin SOIC package with dimensions of 1.5 mm height and 5 mm length facilitates easy mounting on printed circuit boards with limited space.

This receiver IC's differential input thresholds are set at +100mV for high and -100mV for low, ensuring precise signal discrimination for differential signaling applications. It is a part of the FIN1028 series and is designed as a low power, high-performance component for advanced interface designs.

Supports low voltage differential signaling (LVDS) at high speeds. Integrates two receivers and two drivers per chip for efficient operation. Maintenance of performance over wide temperature and voltage ranges. Compact 8-pin SOIC package for surface mount technology applications.

ESD protection enhances device longevity and reliability.

This product is commonly used in industrial, computing, and communication applications requiring high-speed differential data transmission. Explore the Electronics & Electricals category on EnvMart for more LVDS Interface Ics and related semiconductor components to support your design needs.
