Microchip 16 bit Digital Signal Processor 60 MHz 512kB FLASH 44-Pin TQFP DSPIC33EP512GM604-I/PT
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 1.05mm |
| Length | 10mm |
| Model | DSPIC33EP512GM604-I/PT |
| Width | 10mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 85°C |
| Package Type | TQFP |
| Minimum Operating Temperature | -40°C |
| Ram size | 48kB |
| ADC Resolution | 19bit |
| Timer Resolution | 32bit |
| Pin Count | 44 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 3.6V |
| Minimum Supply Voltage | 3V |
| Program Memory Size | 512kB |
| Maximum Clock Frequency | 60MHz |
| Number of Timers | 1 |
| Instruction Set Architecture | Harvard |
| Program Memory Type | FLASH |
| Number of ADCs | 2 |
| Device Million Instructions per Second | 70MIPS |
| Number of PWM Units | 1 |
| PWM Resolution | 16bit |
| ADC Channels | 18 |
| Number of PWM Channels | 12 |
| Microchip, 16 bit Digital Signal Processor 60 MHz 512kB FLASH 44-Pin TQFPBrand | Microchip |
Key Features
- Operates at a maximum clock frequency of 60 MHz providing 70 MIPS performance.
- Features 16 bit data bus width and Harvard instruction set architecture.
- Includes 48kB RAM and 512kB FLASH program memory for extensive application storage.
- Designed with 12 PWM channels and 18 ADC channels for versatile signal processing.
- Package dimensions of 10mm x 10mm with 1.05mm height suitable for surface mounting.
- Supports a minimum supply voltage of 3V and maximum of 3.6V with automotive standard AEC-Q100 compliance.
- Operates reliably in temperatures ranging from -40°C to 85°C for industrial and automotive applications.
- Equipped with 1 timer and 32 bit timer resolution for precise timing control.
Product Description
Microchip DSPIC33EP512GM604-I/PT is a 16-bit Digital Signal Processor featuring a 60 MHz maximum clock frequency and 512kB FLASH memory designed for high-performance embedded applications.
This device incorporates a Harvard instruction set architecture with a 16 bit data bus width and 48kB RAM, optimizing its processing capabilities for digital signal control tasks.
Packaged in a 44-pin Thin Quad Flat Package (TQFP), it has compact dimensions of 10mm in length and width with a height of 1.05mm, making it ideal for dense PCB layouts with surface mount technology.
It supports 12 PWM channels, 18 ADC channels, and features one timer with 32 bit resolution, enabling fine-grained motor control, signal acquisition, and timing measurements.
Operating voltage range is from 3V to 3.6V, with an operating temperature range from -40°C to 85°C, meeting automotive-grade AEC-Q100 standard, thus suitable for automotive, industrial automation, and embedded control applications.
This DSP is well-suited for applications in industrial automation, automotive electronic systems, consumer electronics, and advanced digital signal control systems requiring high-speed computation and extensive memory.
Operates at 60 MHz clock frequency with 70 MIPS throughput. Supports Harvard architecture and 16 bit data bus for efficient processing. Includes 512kB FLASH and 48kB RAM memory for program and data storage. Offers 12 PWM channels and 18 ADC channels for diverse control and sensing functionalities.
AEC-Q100 automotive standard compliance ensures reliability in harsh environments. Compact 44-Pin TQFP package with 10x10x1.05 mm dimensions for easy surface mounting. Wide operating temperature range from -40°C to 85°C for industrial robustness.
Single timer with 32 bit resolution supports precise timing control. Explore other Microchip Digital Signal Processors and microcontrollers in the Electronics & Electricals category on EnvMart for comprehensive embedded solutions.
