STMicroelectronics Operational Amplifier 8 kHz 14-Pin TSSOP 1.5V-5.5V TSU104IPT
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.05mm |
| Length | 5.1mm |
| Model | TSU104IPT |
| Width | 4.5mm |
| Mount Type | Surface |
| Series | TSU104 |
| Output Current | 4mA |
| Maximum Operating Temperature | 85°C |
| Package Type | TSSOP |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 4 |
| Standards/Approvals | RoHS |
| Pin Count | 14 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 1.5V |
| GBP - Gain Bandwidth Product | 8kHz |
| Input Bias Current | 30 pA |
| Vos - Input Offset Voltage | 3.4 mV |
| Slew Rate | 3V/ms |
| Gain bandwidth product | 8 kHz typical |
Key Features
- Features four channels in a compact 14-pin surface mount package.
- Supports low input bias current of 30 pA for precision applications.
- Input offset voltage typically 3.4 mV ensuring stable signal amplification.
- Slew rate of 3 V/ms for responsive performance.
- Wide operating temperature range from -40°C to 85°C supports diverse environments.
- Maximum output current of 4 mA suitable for low-power amplification tasks.
- Package dimensions are 5.1 mm length, 4.5 mm width, and 1.05 mm height.
- Designed to meet RoHS standards for environmental compliance.
Product Description
STMicroelectronics TSU104IPT operational amplifier is a high-performance device designed for precision amplification in electronic circuits. Packaged in a 14-pin TSSOP surface mount format, it features a gain bandwidth product of 8 kHz, making it suitable for low frequency signal amplification needs. The device operates reliably at supply voltages ranging from 1.5V up to 5.5V, allowing flexible integration into various system designs.
This quad-channel operational amplifier boasts a low input bias current of 30 picoamperes and an input offset voltage of 3.4 millivolts, ensuring high accuracy in signal processing applications. The slew rate of 3 volts per millisecond enables rapid voltage changes, contributing to responsive signal handling. With a maximum output current of 4 milliamperes, the TSU104IPT supports low-power load driving effectively.
The operating temperature range from -40°C to 85°C enables its use in industrial and commercial environments where temperature variability is a concern. The package measures 5.1 mm in length, 4.5 mm in width, and 1.05 mm in height, facilitating compact PCB layouts. Compliance with RoHS environmental standards guarantees it meets modern regulatory requirements.
Typical use cases include integration in signal conditioning circuits, instrumentation, and sensor interfaces in industrial automation, consumer electronics, and instrumentation applications. Its surface mount design is optimized for automated assembly, helping to improve production efficiency and reliability in manufacturing processes.
Four-channel design for multiple signal processing. Compact 14-pin TSSOP package suitable for high-density PCB layouts. Low input bias current minimizes signal error in precision circuits. Robust operating temperature range suitable for industrial applications.
Meets environmental RoHS compliance standards. High slew rate supports dynamic signal environments. Low supply voltage operation for energy-efficient designs. Ideal for amplification in sensor and instrumentation applications.
Overall, the STMicroelectronics TSU104IPT is a versatile and reliable operational amplifier solution tailored for industrial, commercial, and instrumentation use cases requiring stable, precise, and low-power signal amplification.
Explore more Operational Amplifiers and semiconductor components at EnvMart for your electronic design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of the TSU104IPT is 8 kHz, making it suitable for low frequency signal amplification needs.
This model operates at supply voltages ranging from 1.5V to 5.5V, allowing for flexible integration into various system designs.
The maximum output current of this operational amplifier is 4 mA, suitable for low-power amplification tasks.
The input offset voltage is typically 3.4 mV, ensuring stable signal amplification in precision applications.
The slew rate of the TSU104IPT is 3 V/ms, which supports responsive performance in dynamic signal environments.
The package dimensions are 5.1 mm in length, 4.5 mm in width, and 1.05 mm in height, facilitating compact PCB layouts.
The input bias current is 30 picoamperes (pA), which minimizes signal error in precision circuits.
This model operates within a temperature range from -40°C to 85°C, making it suitable for diverse environments.
The TSU104IPT features four channels, allowing for multiple signal processing tasks.
This operational amplifier uses a surface mount type, optimized for automated assembly and compact PCB layouts.
Yes, the TSU104IPT meets RoHS standards for environmental compliance, ensuring it adheres to modern regulatory requirements.
Typical applications include integration in signal conditioning circuits, instrumentation, and sensor interfaces in various electronic devices.
