Wurth Elektronik WE-PD2 7850 Shielded Wirewound Surface Mount Inductor with Composite Iron Powder Core 100μH 744787101
Specifications
| Country of Origin | China |
|---|---|
| Brand | Wurth Elektronik |
| Operating Temperature | -40°C up to +125°C |
| Height | 5mm |
| Length | 7.8mm |
| Depth | 7mm |
| Packaging | Tape & Reel |
| Series | WE-PD2 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Composite Iron Powder |
| Inductance | 100μH |
| Standards/Approvals | RoHS, REACH, JEDEC JS709B |
| Package/Case | 7850 |
| Maximum DC Current | 950mA |
| Maximum DC Resistance | 467mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 5MHz |
| Inductor Construction | Self-Centring Shielding Ring |
| Automotive Standard | AEC-Q200 |
Key Features
- Magnetically shielded construction limits electromagnetic interference.
- Designed with a self-centring shielding ring for stable inductance and current handling.
- Compact 7850 package size measuring 7.8mm length, 7mm depth, and 5mm height.
- Supports a maximum DC current of 950mA and maximum DC resistance of 467mΩ.
- Operates reliably in temperature ranges from -40°C to 125°C.
- Offers ±20% inductance tolerance ensuring performance consistency.
- Meets automotive standard AEC-Q200, suitable for automotive and industrial applications.
- Compatible with reflow soldering processes for efficient PCB assembly.
Product Description
Wurth Elektronik 744787101 WE-PD2 series shielded wirewound surface mount inductor features a composite iron powder core with magnetically shielded construction enhancing its electrical performance and reducing electromagnetic interference. This 100μH inductor is designed with a self-centring shielding ring that ensures stable inductance and current handling capabilities.
The compact 7850 package size with dimensions 7.8mm length, 7mm depth, and 5mm height makes it ideal for tight PCB layouts in automotive and industrial electronics. It supports a maximum DC current of 950mA and exhibits a maximum DC resistance of 467mΩ, maintaining efficiency under load conditions.
Operating temperature range from -40°C up to 125°C allows reliable use in harsh environments and automotive conditions. The component offers ±20% inductance tolerance compliant with AEC-Q200 automotive standards, making it suitable for automotive power supply and filtering applications.
The WE-PD2 series inductor complies with RoHS, REACH regulations, and JEDEC JS709B standards, ensuring environmental safety and industry standard quality. It is compatible with reflow soldering processes facilitating straightforward manufacturing integration.
This power inductor is ideal for electronic, automotive, manufacturing, and industrial device implementations where stable inductance and high current handling are required. Its shielding and compact surface mount design improve electromagnetic compatibility and circuit efficiency.
Magnetically shielded construction limits electromagnetic interference. Self-centring shielding ring ensures stable inductance and current handling. Compact 7850 package with 7.8mm length, 7mm depth, and 5mm height. Maximum DC current rating of 950mA and DC resistance of 467mΩ.
Operating temperature from -40°C to 125°C. ±20% inductance tolerance for performance consistency. Meets automotive standard AEC-Q200 and environmental standards RoHS, REACH, JEDEC JS709B. Compatible with standard reflow soldering processes.
Explore a comprehensive range of power inductors and Surface Mount Inductors at EnvMart for your industrial and electronic component needs.
