Wurth Elektronik 1812 Unshielded Surface Mount Common Mode Line Filter with Ferrite Core 11μH Dual Inductor 744235110

Wurth Elektronik 744235110 is a high-quality 1812 unshielded surface mount common mode line filter equipped with a ferrite core and dual inductor construction. With an inductance rating of 11μH, this component delivers excellent common mode noise suppression especially at high frequencies, making it ideal for modern electronic circuit designs requiring EMI control.

The winding symmetry of the WE-CNSW series minimizes interference with high-speed signals, supporting applications including USB 2.0, Firewire, LVDS, LAN interfaces, and other high-speed data lines where signal integrity is paramount.

It supports a maximum DC current of 450mA and features a maximum DC resistance of 800mΩ with an inductance tolerance ranging from -30% to +50%. This device conforms to the stringent AEC-Q200 automotive standard, offering robust performance across an operating temperature range from -40°C up to 125°C.

The physical package is a standard 1812 case size with precise dimensions: 4.5mm in length, 3.2mm in depth, and 2.8mm in height. The component is supplied in tape and reel packaging to facilitate efficient automated PCB assembly. The termination style is surface mount with 4 pins, suitable for various mounting equipment in electronics manufacturing.

Manufactured with a ferrite core material and compliant with RoHS environmental standards, this common mode choke is not moulded and does not feature shielding. It is produced in Taiwan Province Of China according to quality manufacturing practices.

Used widely in industrial, automotive, communications, and consumer electronics sectors, this common mode line filter is critical for filtering out unwanted EMI noise and ensuring compliance with electromagnetic compatibility regulations.

High common mode suppression at high frequencies. Minimal signal interference due to winding symmetry. Supports maximum DC current of 450mA. Meets AEC-Q200 automotive standards ensuring durability. Operating temperature range from -40°C to 125°C.

1812 package size with compact dimensions for PCB space-saving. Tape and reel packaging for automated assembly. RoHS compliant ferrite core construction. Surface mount termination with 4 pin count. Explore our extensive range of Surface Mount Inductors and filters at EnvMart for your electronic component requirements.
