Samtec TLW Series Straight Through Hole Pin Header, 16 Contact(s), 2.54 mm Pitch, 2 Row, Unshrouded TLW-108-05-G-D

Samtec TLW-108-05-G-D is a high-quality straight through hole pin header featuring 16 male contacts arranged across 2 rows with a 2.54 mm pitch. The header is designed for through-hole mounting on PCBs and is unshrouded, providing ease of access for soldering and inspection.

Constructed with phosphor bronze contacts plated with 0.25μm gold and gold flash on tails, these headers ensure excellent electrical conductivity and corrosion resistance. The housing uses black liquid crystal polymer, which offers robust mechanical strength and thermal stability.

Rated for a current of 3 A per contact, the header operates efficiently within a temperature range of -55°C to 125°C, making it suitable for diverse industrial and electronic applications. The tail pin length measures 4.32 mm, and the mating pin length is 2.67 mm, dimensions that contribute to secure mechanical and electrical connections.

This TLW series product is ideal for board-to-board and wire-to-board connections in electronic assemblies, providing a reliable and low-profile connecting solution. Through-hole solder termination type ensures lasting and robust mounting.

Features a 2.54 mm pitch for precise PCB interfacing. Contains 16 male contacts arranged in 2 unshrouded rows. Constructed with phosphor bronze contacts plated with 0.25μm gold for durability. Equipped with a black liquid crystal polymer housing ensuring high mechanical strength.

Supports currents up to 3 A per contact. Designed for through-hole mounting, enhancing connection stability. Operating temperature range spans from -55°C to 125°C for versatile application. Tail pin length is 4.32 mm, with mating pin length 2.67 mm for secure connections.

Suitable for board-to-board and wire-to-board connector systems. Termination type is solder, ensuring reliable electrical contact.

This pin header is widely used in industrial electronics, power connectors, manufacturing PCB assemblies, and commercial electronic devices. Samtec products are known for their quality and precision in various industrial and laboratory environments. Browse the PCB Headers category on EnvMart for compatible connectors and accessories.
