Microchip 2-Channel 16 bit Delta Sigma Analog to Digital Converter 0.02 ksps, 8-Pin MSOP MCP3426A0-E/MS
Specifications
| Country of Origin | India |
|---|---|
| Resolution | 16 bit |
| Brand | Microchip |
| Height | 1.1mm |
| Length | 3.1mm |
| Model | MCP3426A0-E/MS |
| Mount Type | Surface |
| Sampling rate | 0.02ksps |
| Series | MCP3426 |
| Input Type | Voltage |
| Maximum Operating Temperature | 125°C |
| Package Type | MSOP |
| Minimum Operating Temperature | -40°C |
| Interface Type | Serial-I2C |
| Architecture | Delta Sigma |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 703-7951PBrand: MicrochipManufacturers Part No.: MCP3426A0-E/MS |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 2.7V |
| Number of ADCs | 2 |
| Programable Data rate options are | 15 SPS, 60 SPS or 240 SPS |
Key Features
- Features 2 ADC channels using Delta Sigma architecture for high precision conversion.
- Offers programmable data rate options of 15 SPS, 60 SPS, or 240 SPS for flexible sampling.
- Operates from 2.7V minimum supply voltage up to 5.5V maximum supply voltage.
- Supports serial I2C interface for easy integration in digital systems.
- Designed to operate over -40°C to 125°C, meeting automotive AEC-Q100 standards.
- Compact 8-pin MSOP package with dimensions 3.1mm length and 1.1mm height.
- Ideal for industrial and automotive applications requiring accurate analog to digital conversion.
Product Description
Microchip MCP3426A0-E/MS is a precision 2-channel 16 bit analog to digital converter employing Delta Sigma architecture to ensure high accuracy and minimal noise in signal acquisition. The device is housed in a compact 8-pin MSOP surface mount package with a length of 3.1mm and height of 1.1mm, designed for space-constrained electronic assemblies.
It supports programmable sampling rates of 15 SPS, 60 SPS, or 240 SPS, with a base sampling rate of 0.02 ksps, allowing flexibility in balancing speed and precision for various applications. The device operates within a voltage range of 2.7V to 5.5V and supports serial I2C communication interface, enabling straightforward connectivity to microcontrollers and digital processing units.
Rated for an operating temperature range from -40°C to 125°C, this ADC is qualified to meet the automotive standard AEC-Q100, making it suitable for demanding environments in automotive, industrial control systems, instrumentation, and measurement equipment.
Features 2 ADC channels using Delta Sigma architecture for high precision conversion. Offers programmable data rate options of 15 SPS, 60 SPS, or 240 SPS for flexible sampling. Operates from 2.7V minimum supply voltage up to 5.5V maximum supply voltage.
Supports serial I2C interface for easy integration in digital systems. Designed to operate over -40°C to 125°C, meeting automotive AEC-Q100 standards. Compact 8-pin MSOP package with dimensions 3.1mm length and 1.1mm height.
Ideal for high precision measurements in industrial, automotive, and electronics applications.
This Microchip MCP3426A0-E/MS ADC is a reliable choice for high accuracy data conversion needs in electronic design and manufacturing. Browse more semiconductor and ADC products in the Electronics & Electricals category at EnvMart for your project requirements.
Explore more products in our Analogue to Digital Converter category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a resolution of 16 bits, allowing for high precision in analog to digital conversion.
It offers programmable data rate options of 15 SPS, 60 SPS, or 240 SPS, providing flexibility for various application needs.
It operates with a minimum supply voltage of 2.7V and a maximum supply voltage of 5.5V.
This ADC is designed to operate over a temperature range of -40°C to 125°C, suitable for demanding environments.
This model features 2 ADC channels, allowing for simultaneous data acquisition from multiple sources.
It supports a serial I2C interface, making it easy to integrate with digital systems.
The device is housed in an 8-pin MSOP package with dimensions of 3.1mm in length and 1.1mm in height.
Yes, it is qualified to meet the automotive standard AEC-Q100, ensuring reliability in automotive applications.
It employs Delta Sigma architecture, which provides high accuracy and minimal noise in signal acquisition.
The maximum operating temperature for the MCP3426A0-E/MS is 125°C.
This model can operate at a minimum temperature of -40°C.
It has a voltage input type, suitable for various analog signals.
