Preci-Dip 803 Series Right Angle PCB Socket 18-Contact 2 Row 2.54 mm Pitch Solder 803-87-018-20-001101

Free Delivery in India | Lowest Global Shipping Charges

Preci-Dip 803 Series Right Angle PCB Socket 18-Contact 2 Row 2.54 mm Pitch Solder 803-87-018-20-001101

Name: Preci-Dip 803 Series Right Angle PCB Socket 18-Contact 2 Row 2.54 mm Pitch Solder 803-87-018-20-001101
Brand: Preci-Dip
SKU: 353491
Price: 5.62 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand Preci-Dip Condition New

Specifications

Country of Origin	Switzerland
Voltage	150V
Brand	Preci-Dip
Orientation	Right Angle
Current	12A
Mount Type	PCB
Housing Material	Black Glass Filled Polyester
Contact Material	Beryllium Copper Alloy
Series	803
Termination Type	Solder
Maximum Operating Temperature	125°C
Sub Type	Board-to-Board
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Pay online using	Or choose to pay later via bank transfer
Contact Plating	Gold Flash
Number of Contacts	18
Contact Gender	Female
Connector System	Board-to-Board

Key Features

Manufactured with black glass filled polyester housing ensuring durability and stability.
Contacts made of beryllium copper alloy with gold flash plating for superior conductivity.
Rated for 12A current and 150V voltage suitable for moderate power applications.
Designed for right angle PCB mounting with solder termination for secure installation.
Operating temperature range from -55°C to 125°C for varied environmental conditions.
Featuring two rows of female contacts enabling board-to-board connectivity.
Complies with Swiss manufacturing standards and UL 94V-0 for flammability rating.
Ideal for industrial electronics, control systems, and PCB interconnect applications.

Product Description

Preci-Dip 803-87-018-20-001101 is a high-quality right angle PCB socket designed for precise board-to-board connections in electronic assemblies. This socket features 18 female contacts arranged in two rows, each with a standard 2.54 mm pitch that fits most PCB designs requiring reliable and compact interconnect solutions.

The housing is made of black glass filled polyester, offering robust insulation and mechanical strength, ideal for demanding industrial and laboratory environments. Contact elements are crafted from beryllium copper alloy with gold flash plating, which ensures excellent electrical conductivity and resistance to corrosion, enhancing the socket’s durability over time.

Engineered for solder mounting on PCBs, this right angle socket supports a current rating of 12 amperes and a voltage rating of 150 volts, making it suitable for a variety of moderate power electronics applications. The product can operate reliably in extreme temperatures ranging from -55°C to 125°C, covering a wide spectrum of operational environments.

Preci-Dip sockets in the 803 series are recognized for their precise mechanical fit and compliance with UL 94V-0 flammability standards, ensuring safety and performance. The right angle orientation supports compact PCB layouts and facilitates efficient routing of board-to-board connections.

Black glass filled polyester housing for strength and insulation. Beryllium copper alloy contacts with gold flash plating for optimal conductivity. Solder termination ensures permanent and reliable PCB mounting. Electrical ratings of 12A current and 150V voltage.

Operating temperature range from -55°C up to 125°C. Board-to-board connector system with 18 female contacts, 2 rows. Produced in Switzerland maintaining high manufacturing standards. Suitable for electronics manufacturing, industrial controls, and prototyping.

Explore more electronics components in the PCB Sockets category and discover comprehensive connectors solutions by Preci-Dip at EnvMart.

Explore more products in our Electronic Components, Power & Connectors category.
