Preci-Dip 803 Series Right Angle PCB Socket 4-Contact 2 Row 2.54 mm Pitch Solder 803-87-004-20-001101

Preci-Dip 803-87-004-20-001101 Right Angle PCB Socket 4-Contact 2 Row 2.54 mm Pitch Solder is engineered for secure and efficient board-to-board electrical connections in electronic devices. The socket features a 2.54 mm pitch across two rows with 4 female contacts, offering compact and reliable mating with compatible headers.

The housing is made from black glass filled polyester which provides robust mechanical support and excellent resistance to heat and chemicals. Contact pins are crafted from beryllium copper alloy and plated with a gold flash finish to ensure high electrical conductivity and prevent corrosion over extended use.

This PCB socket is designed with a right-angle orientation optimized for soldering to printed circuit boards, making it suitable for both surface mount and through-hole processes. It can safely carry currents up to 12 amperes and voltages up to 150 volts, enabling use in a broad range of industrial, laboratory, manufacturing, and electronics assembly settings.

Operating temperature range from -55°C to +125°C supports use in harsh environmental conditions. The product meets UL 94V-0 fire safety standards, assuring compliance with international safety regulations.

With Swiss manufacturing origin, this 803 series socket is a precision-engineered component tailored for demanding electronics applications that require secure, durable, and reliable PCB connectors.

Features a 2-row, 4-contact configuration with 2.54 mm pitch. Constructed with black glass filled polyester housing for durability. Contact material uses beryllium copper alloy with gold flash plating for excellent conductivity and corrosion resistance.

Right angle orientation designed for solder termination on PCB mounting. Rated for 12 A current and 150 V voltage to suit various electronic applications. Operates reliably between -55°C and 125°C temperature range. Complies with UL 94V-0 flammability standard for safety.

Manufactured in Switzerland ensuring high quality and precision.

This PCB socket is ideal for use in electronics, industrial equipment, manufacturing assemblies, laboratory instrumentation, and other commercial applications requiring high quality connectors. Explore the Electronics Components category on EnvMart for more PCB connector solutions.
