Omron Slide Rotary Coded DIP Switch Surface Mount A6S-2101-H
Specifications
| Country of Origin | China |
|---|---|
| Brand | Omron |
| Model | A6S-2101-H |
| Mount Type | Surface Mount |
| Actuator Type | Slide |
| Insulation resistance | 100MΩ min at 250Vdc |
| Contact Resistance | 200mΩ max |
| Mechanical Life | 1000 operations |
Key Features
- Designed for surface mount installation following Dual Inline (DIL) standards.
- Equipped with a slide actuator type for smooth operation.
- Features gold plated contacts for enhanced conductivity and corrosion resistance.
- Provides a maximum contact resistance of 200mΩ ensuring low signal loss.
- Insulation resistance is rated at 100MΩ minimum at 250V DC for electrical safety.
- Engineered to last for 1000 mechanical operations guaranteeing durability.
- Flat actuators are available as sealed tape versions for easy automatic mounting with IC insertion machines.
Product Description
Omron A6S-2101-H Slide Rotary Coded DIP Switch Surface Mount is a high-quality slide switch designed for precise rotary coded switching functions in electrical and automation systems.
This switch is surface mountable and constructed to meet Dual Inline (DIL) standards, allowing for seamless integration in printed circuit board (PCB) designs with automatic IC insertion machinery.
Its slide actuator type encourages reliable toggle action, supported by gold plated contacts that ensure excellent electrical conductivity and robustness against wear and corrosion.
The device is rated with a maximum contact resistance of 200mΩ and a high insulation resistance of at least 100MΩ at 250 volts DC, providing safety and consistent performance in demanding environments.
Designed for mechanical longevity, it is rated for 1000 operations, making it ideal for industrial, laboratory, manufacturing, and automation use cases requiring dependable switching solutions.
Flat actuators available in sealed tape versions enhance production efficiency through compatibility with automated insertion lines. Designed for surface mount installation following Dual Inline (DIL) standards. Slide actuator type delivers precise switching control.
Gold plated contacts provide excellent conductivity and corrosion resistance. Contact resistance maximum of 200mΩ for dependable signal quality. Insulation resistance minimum of 100MΩ at 250V DC to ensure electrical safety.
Mechanical life of 1000 operations ensures reliability over time. Flat actuator sealed tape versions available for automation compatibility. This Rotary Coded DIP Switch is widely useful in electronics manufacturing, machinery control panels, and automated systems requiring compact, reliable switch components.
Discover more quality electrical switches in the Switches & Sockets category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The insulation resistance is rated at a minimum of 100MΩ at 250V DC, ensuring electrical safety.
It is rated for 1000 mechanical operations, providing reliability over time.
This switch is designed for surface mount installation, adhering to Dual Inline (DIL) standards.
The maximum contact resistance is 200mΩ, ensuring low signal loss.
It features a slide actuator type for smooth operation and precise switching control.
The country of origin for this switch is China.
The contacts are gold plated, which enhances conductivity and provides corrosion resistance.
Yes, flat actuators are available in sealed tape versions, making it compatible with automatic IC insertion machinery.
It is widely useful in electronics manufacturing, machinery control panels, and automated systems requiring reliable switch components.
The slide actuator allows for reliable toggle action, enhancing the precision of the switching function.
It is designed for surface mount installation, which should follow Dual Inline (DIL) standards for optimal integration.
This switch is suitable for demanding environments due to its high insulation resistance and robust construction.
