TE Connectivity AMPMODU MOD II Series Straight Through Hole Pin Header, 8 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded 826656-4
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 750V |
| Brand | TE Connectivity |
| Orientation | Straight |
| Current | 3A |
| Model | 826656-4 |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Brass |
| Series | AMPMODU MOD II |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -65°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Tail Pin Length | 3.2mm |
| Mating Pin Length | 5.8mm |
Key Features
- Features 8 straight male pins arranged in 2 rows for versatile applications.
- Constructed with polybutylene terephthalate housing for durability.
- Brass contacts plated with gold ensure excellent conductivity and corrosion resistance.
- Designed for through-hole mounting with solder termination.
- Supports up to 3A current and 750V voltage rating.
- Operates reliably between -65°C and 105°C temperature range.
- Unshrouded design allows easy pin access and flexibility.
- Pin lengths of 3.2 mm tail and 5.8 mm mating promote secure connections.
Product Description
TE Connectivity 826656-4 AMPMODU MOD II Series Straight Through Hole Pin Header offers an 8-contact unshrouded double row pin header with 2.54 mm pitch. This connector is engineered to deliver consistent and economical interconnections for electronics assemblies requiring board-to-board or wire-to-board connections.
Manufactured with a polybutylene terephthalate housing and brass contacts plated with gold, the header ensures high durability, conductivity, and corrosion resistance. The through-hole mount type and solder termination facilitate easy PCB integration with labor-saving installation techniques. It supports a maximum current rating of 3A and voltage rating of 750V, operating reliably within a temperature span of -65°C to 105°C.
The AMPMODU MOD II system is recognized for its compact and modular design suitable for industrial automation, telecommunications, medical instruments, computers, storage equipment, automotive controls, and test equipment. Its unshrouded, breakaway form factor enables customization of pin count and adaptable use in various electronic applications.
The header pins have a tail length of 3.2 mm and mating length of 5.8 mm, ensuring solid mechanical and electrical contact. These attributes contribute to reliable signal transmission and long service life in demanding environments.
Features 8 straight male pins arranged in 2 rows for versatile applications. Constructed with polybutylene terephthalate housing for durability. Brass contacts plated with gold ensure excellent conductivity and corrosion resistance.
Designed for through-hole mounting with solder termination. Supports up to 3A current and 750V voltage rating. Operates reliably between -65°C and 105°C temperature range. Unshrouded design allows easy pin access and flexibility.
Pin lengths of 3.2 mm tail and 5.8 mm mating promote secure connections.
This TE Connectivity AMPMODU MOD II pin header is ideal for industrial, laboratory, telecommunications, automotive, and commercial electronic equipment assemblies requiring robust, compact interconnects. Explore EnvMart for additional connectors and PCB hardware solutions.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum current rating of 3A and a voltage rating of 750V.
The contacts of this pin header are arranged with a pitch of 2.54 mm.
It features a polybutylene terephthalate housing and brass contacts plated with gold for enhanced conductivity and corrosion resistance.
This pin header operates reliably within a temperature range of -65°C to 105°C.
This model has 8 contacts arranged in 2 rows.
It utilizes a solder termination type, designed for through-hole mounting.
The tail pin length is 3.2 mm, while the mating pin length is 5.8 mm.
The contacts are arranged in a straight orientation.
It is suitable for board-to-board and wire-to-board connections in various applications, including industrial automation and telecommunications.
This model is designed as an unshrouded pin header, allowing easy access to the pins.
The country of origin for this pin header is India.
It is part of the AMPMODU MOD II connector system, designed for versatile electronic applications.
