Texas Instruments 1 Flip Flop IC LVC, 8-Pin SSOP, Operating Voltage 1.65 to 5.5 V SN74LVC2G74DCTR

Texas Instruments SN74LVC2G74DCTR is a 1 Flip Flop IC from the 74LVC2G family, implemented with Low-Voltage CMOS logic technology. This device operates within a voltage range of 1.65 to 5.5 V and comes in an 8-pin SSOP surface mount package, ideal for compact and high-density circuit designs.

The IC features a single positive edge triggered D-type flip-flop element per chip, capable of operating with inverting and non-inverting polarity. It supports clock frequencies up to 200 MHz, enabling fast switching capabilities suitable for high-speed digital circuits. The propagation delay time is as low as 4.4 ns at typical loading conditions, which ensures quick response times in timing-critical applications.

This device is designed to be compatible with input voltage levels of LVTTL and TTL and provides LVCMOS output levels, making it versatile for interfacing between different logic families. The operating temperature range spans from -40°C to 85°C, suitable for industrial and commercial environmental conditions.

The SSOP package dimensions are compact, with a height of 1.29 mm and length of 2.95 mm, reducing PCB space and facilitating modern electronics miniaturization. Logic Family: Low-Voltage CMOS (LVC). Package Type: SSOP, 8-pin surface mount.

Operating Voltage: 1.65 to 5.5 V. Clock Frequency: 200 MHz maximum. Propagation Delay: 4.4 ns at CL. Operating Temperature: -40°C to 85°C. Polarity: Inverting, Non-Inverting. Compatibility: Input LVTTL/TTL, Output LVCMOS.

Height: 1.29 mm; Length: 2.95 mm.

This product is suitable for industrial electronics, embedded systems, communication devices, and other applications requiring reliable digital flip-flop functionality with low voltage operation.
