Omron Roller Lever Micro Switch, PCB Terminal, 100mA, 30 V dc, SPDT, IP67 D2SW-P01L2B

Omron D2SW-P01L2B Roller Lever Micro Switch is a high-quality sealed subminiature microswitch with a roller lever actuator and PCB terminal connections. It is designed for precise and reliable switching applications in demanding industrial, electronics, and automation environments. The product supports a maximum switching current of 100mA and a DC voltage rating of 30 V, ensuring safe operation in low voltage circuits.

This micro switch features a single pole double throw (SPDT) contact configuration, enabling diverse switching tasks. It possesses an IP67 rating, offering robust protection against dust ingress and water immersion, making it ideal for harsh or wet conditions. The sealed miniaturized monoblock construction increases longevity and resistance to environmental factors.

The switch has an operating force of 0.6 newtons and a mechanical life expectancy rated at 1 million operations. It is compact with a 6.4 mm depth and 19.8 mm length, suitable for PCB mounting in industrial equipment, machinery controls, or automation systems. The operating temperature range extends from -40°C to +80°C, allowing functionality across varied climatic conditions.

Omron’s D2SW-P01L2B switch is compliant with RoHS standards and RoHS certified, ensuring environmentally friendly manufacturing. The switch’s reliable performance and compact form factor make it suitable for uses in electronics manufacturing, industrial machine control panels, HVAC systems, automotive applications, and instrumentation.

Package contents typically include one sealed roller lever Micro Switch with PCB terminals. This product provides the durability and precise operation needed for critical switching applications.

Operates with a maximum current of 100mA. Supports contact DC voltage up to 30 V dc. Features a single pole double throw (SPDT) contact configuration. Rated IP67 for protection against dust and water. Compact sealed subminiature design.

Mechanical life expectancy of 1,000,000 operations. Operating force of 0.6 N. Operating temperature range from -40°C to +80°C. Dimensions include 6.4 mm depth and 19.8 mm length. Explore the Electronics & Electricals category at EnvMart for more high-quality switches and components tailored to industrial and commercial applications.
