Microchip 2-Channel General Purpose Comparator Push Pull Output 20 ns Response Time 3 V-5.5 V 8-Pin SOIC MCP6562-E/SN
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 1.25mm |
| Length | 4.9mm |
| Model | MCP6562-E/SN |
| Width | 3.9mm |
| Mount Type | Surface |
| Output type | Push Pull |
| Series | MCP6562 |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Comparator Type | General Purpose |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 3V |
| Supply Current | 100μA |
| Typical Response Time | 20ns |
Key Features
- Provides dual comparator channels in a single 8-pin SOIC package.
- Push pull output enhances signal integrity and drive capability.
- Fast response time of 20 nanoseconds suitable for high-speed applications.
- Operates over a wide supply voltage range from 3 V to 5.5 V.
- Surface mount package suitable for compact PCB designs.
- Wide operating temperature range from -40°C to 125°C for industrial reliability.
- Low supply current of 100 µA to minimize power consumption.
- Complies with automotive standard AEC-Q100 for quality and reliability.
Product Description
The Microchip MCP6562-E/SN is a high-performance dual comparator designed for general purpose applications requiring fast response and low power consumption. This 2-channel comparator operates with a supply voltage from 3 volts minimum up to 5.5 volts maximum, making it suitable for battery-powered and low voltage systems.
Featuring push pull output stages, the device ensures robust signal driving capability with minimized output distortion. It integrates two comparator channels within an 8-pin Small Outline Integrated Circuit (SOIC) package that is surface mount compatible, allowing for streamlined manufacturing and compact device footprint on printed circuit boards.
Boasting a very rapid typical response time of 20 nanoseconds, this comparator is well-suited for high-speed signal detection and processing in industrial, automotive, instrumentation, and control systems. The device’s operational temperature range from -40°C to 125°C further enables deployment in harsh and demanding environments, while maintaining performance and stability.
With a low supply current of 100 microamps, the MCP6562-E/SN is optimized for energy-conscious designs without compromising switching speed or output drive. It meets the automotive quality standard AEC-Q100, ensuring reliability in critical automotive electronic systems.
Dual general purpose comparator channels in an 8-pin SOIC package. Push pull output configuration for enhanced signal drive. Typical response time of 20 nanoseconds for high-speed switching. Wide operating supply voltage range, 3 V to 5.5 V.
Surface mount package for compact PCB integration. Extended operating temperature range from -40°C to 125°C. Low supply current of 100 µA conserves power. Automotive grade AEC-Q100 qualification for reliability. Exact physical dimensions: 4.9 mm (L) x 3.9 mm (W) x 1.25 mm (H).
This Microchip comparator finds application in electronic circuits that require precision voltage comparison, signal conditioning, and quick switching capabilities. Ideal usage areas include industrial automation, automotive sensor interfacing, power management, and instrumentation.
Explore a wide range of Semiconductor Comparators and amplifiers at EnvMart for your next design project.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The typical response time of this model is 20 nanoseconds, making it suitable for high-speed applications.
It operates over a supply voltage range from 3 V to 5.5 V, allowing for flexibility in various applications.
This model features two comparator channels integrated within a single package.
It has a push pull output configuration, which enhances signal integrity and drive capability.
The dimensions of this model are 4.9 mm in length, 3.9 mm in width, and 1.25 mm in height.
It operates within a temperature range from -40°C to 125°C, suitable for industrial applications.
The supply current is 100 microamps, which helps minimize power consumption.
Yes, it complies with the automotive standard AEC-Q100 for quality and reliability.
It comes in an 8-pin Small Outline Integrated Circuit (SOIC) package, suitable for surface mounting.
This comparator is suitable for applications in industrial automation, automotive sensor interfacing, power management, and instrumentation.
It is a general-purpose comparator designed for a variety of applications requiring fast response and low power consumption.
The push pull output configuration enhances the signal driving capability and minimizes output distortion, improving performance in signal processing.
