Sunhayato Single-Sided Matrix Board FR4 Epoxy Glass Fabric Laminate 1.6 mm Thickness 0.9 mm Hole Diameter ICB-141GD-PBF

Sunhayato ICB-141GD-PBF is a single-sided matrix board designed with FR4 epoxy glass fabric laminate, featuring a board thickness of 1.6 mm and hole diameters of 0.9 mm. The board measures 180 mm in length and 130 mm in width, providing an optimal surface for mounting various electronic components.

This medium-sized universal lead-free matrix board offers reliable mechanical support and excellent electrical insulation, meeting the requirements for high-quality electronic prototyping and circuit design. The FR4 material grade indicates a flame-retardant quality that enhances safety in industrial and laboratory settings.

The matrix board includes a uniformly spaced hole pitch of 2.54 mm and board installation holes ranging from 3.2 mm to 4 mm, suitable for standard pin configurations and mounting hardware. It complies with industry standards such as BS EN 61340 and ANSI/ESD S20 to ensure electrostatic discharge protection, critical during sensitive circuit assembly and testing operations.

Manufactured in Japan, this board benefits from stringent quality control and precise fabrication processes, offering long-lasting durability and consistent performance. It is ideal for electronics manufacturers, engineering laboratories, industrial prototyping, and educational applications requiring a robust and standardized prototyping surface.

The matrix board supports single-digit 7-segment blue LED displays from Broadcom, enhancing display and control applications. It suits a wide range of industrial, electronic, and laboratory prototyping tasks requiring reliable component mounting and circuitry testing.

Its lead-free composition aligns with global environmental standards and safety regulations. Explore EnvMart’s extensive range of high-quality Matrix Boards and prototyping solutions designed for electronics and electrical component manufacturing and development.
