Crydom Solid State Relay, 35 A Load Current, DIN Rail Mount, 530 V Load Voltage, 32V Control CMR48
Specifications
| Country of Origin | India |
|---|---|
| Brand | Crydom |
| Height | 76.2mm |
| Length | 109mm |
| Model | CMR48 |
| IP Rating | IP20 |
| Width | 44.5mm |
| Mount Type | DIN Rail |
| Output type | SCR |
| Series | CMR48 |
| Maximum Operating Temperature | 80°C |
| Contact Configuration | SPST |
| Capacitance | 8pF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Screw |
| Switching Function | Zero Cross Switching |
| Maximum Load Current | 35A |
| Standards/Approvals | RoHS |
| Maximum Load Voltage | 530V |
| Minimum Load Voltage | 48V ac |
| Minimum Control Voltage | 4V dc |
| Maximum Control Voltage | 32V |
| Off State Leakage Current | 10mArms |
Key Features
- Solid state relay supports 35 A load current and 530 V load voltage.
- DIN rail mounting ensures quick and secure installation.
- Zero cross switching minimizes electrical noise and extends equipment life.
- Green LED indicator provides clear operation status.
- Rated for operation up to 80°C for reliable industrial performance.
- Compact dimensions of 109 mm length, 76.2 mm height, and 44.5 mm width.
- RoHS compliant design with screw terminal connections.
- Suitable for automation, motor manufacturing, and warehouse applications.
Product Description
Crydom CMR48 Solid State Relay is a durable and efficient electronic switching device designed for industrial automation, control systems, and manufacturing applications. Featuring a maximum load current of 35 A and load voltage rating of 530 V, it offers reliable performance with minimal maintenance due to absence of mechanical parts.
The relay mounts securely on standard DIN rails, facilitating fast integration into electrical panels and control cabinets. Its zero cross switching function greatly reduces electrical interference and extends the lifespan of connected equipment. Operating at control voltages from 4V dc minimum up to a maximum of 32V, it supports flexible control inputs.
Equipped with screw-type terminals, the relay provides reliable connections and ease of installation. Its compact size (109 mm length, 76.2 mm height, 44.5 mm width) and IP20 rating ensure it fits neatly in tight spaces while offering basic protection against accidental contact.
An integrated green LED indicator enables users to monitor the relay's operating status at a glance. The device is RoHS compliant and built to withstand operating temperatures ranging from -40°C to 80°C, making it suitable for challenging industrial environments.
This relay is ideal for automation systems requiring silent, rapid switching without mechanical wear. Commonly used in motor control, industrial machinery, and process control where reliable solid state relays prevent downtime.
Its dielectric strength of 4000 Vrms ensures safe, insulated operation under high voltage conditions. The off-state leakage current is low at 10mArms, reducing power loss during standby. Capacitance of 8pF supports efficient signal handling with minimal noise.
Equip your industrial equipment or automation project with the Crydom CMR48 series for dependable high-current control. This solid state relay combines convenience, safety, and operational longevity in a compact DIN rail package.
Browse EnvMart's comprehensive selection of Crydom Solid State Relays to match your specific load and control requirements with confidence.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum load current for this model is 35 A.
It has a load voltage rating of 530 V.
This relay supports control voltages from a minimum of 4 V dc up to a maximum of 32 V.
The dimensions of this unit are 109 mm in length, 76.2 mm in height, and 44.5 mm in width.
It is designed for DIN rail mounting, allowing for quick and secure installation.
The operating temperature range is from -40°C to 80°C.
Yes, this model features zero cross switching, which minimizes electrical noise and extends equipment life.
It uses screw-type terminals for reliable connections and ease of installation.
The IP rating of this relay is IP20, providing basic protection against accidental contact.
The off-state leakage current is low at 10 mArms, reducing power loss during standby.
Yes, this relay is RoHS compliant, ensuring it meets environmental standards.
It is suitable for automation, motor manufacturing, and warehouse applications.
