Renesas Electronics 16-Bit Non-Inverting 3 State Bus Transceiver, 20-Pin QSOP 74FCT245ATQG

Free Delivery in India | Lowest Global Shipping Charges

Renesas Electronics 16-Bit Non-Inverting 3 State Bus Transceiver, 20-Pin QSOP 74FCT245ATQG

Name: Renesas Electronics 16-Bit Non-Inverting 3 State Bus Transceiver, 20-Pin QSOP 74FCT245ATQG
Brand: Renesas Electronics
SKU: 321554
Price: 0.74 USD
Availability: InStock



Category Bus Transceivers Brand Renesas Electronics Condition New

Specifications

Country of Origin	India
Brand	Renesas Electronics
Height	1.47mm
Length	8.7mm
Model	74FCT245ATQG
Mount Type	Surface
Output type	3 State
Series	74FCT
Maximum Operating Temperature	85°C
Package Type	QSOP
Minimum Operating Temperature	-40°C
Polarity	Non-Inverting
Number Of Channels	16
Pin Count	20
Maximum Supply Voltage	7V
Logic Family	74FCT
Logic Function	Bus Transceiver
Minimum Supply Voltage	-0.5V
Maximum Propagation Delay Time @ CL	4.1ns
Output Level	3 State
Input Level	CMOS

Key Features

Designed for asynchronous two-way communication between data buses.
16-bit non-inverting transceiver with 3-state outputs.
20-pin QSOP surface-mount package.
Low input and output leakage current of less than or equal to 1 µA.
True TTL input and output compatibility with VOH of 3.3V and VOL of 0.3V typically.
High drive outputs with -15mA IOH and 64mA IOL capability.
Meets or exceeds JEDEC standard 18 specifications.
Power-off disables outputs allowing live insertion.

Product Description

Renesas Electronics 74FCT245ATQG is a 16-bit non-inverting 3-state bus transceiver designed to enable asynchronous bidirectional communication between data buses in electronic circuits.

This device features a 20-pin QSOP surface-mount package suitable for compact PCB designs. The transceiver provides low input and output leakage currents of less than or equal to 1 µA, ensuring minimal power consumption in high-speed logic circuits.

It supports true TTL input and output compatibility with typical output high voltage of 3.3V and output low voltage of 0.3V. The high drive capability of -15mA IOH and 64mA IOL supports driving various loads effectively.

The 74FCT245ATQG meets or exceeds JEDEC standard 18 specifications, ensuring reliable and standardized performance. It includes power-off disable outputs permitting live insertion to prevent damage during hot swapping operations.

Operating temperature range spans from -40°C to 85°C, allowing usage in industrial, commercial, and automotive electronics environments. Its compact height of 1.47mm and length of 8.7mm make it ideal for space-constrained applications.

Designed for asynchronous two-way communication between data buses. 16-bit non-inverting transceiver with three-state outputs for bus driving. 20-pin QSOP surface-mount package suitable for compact electronic designs. Extremely low input/output leakage current of ≤1 µA minimizing power consumption.

True TTL input/output compatibility ensures easy integration with TTL logic. High drive capabilities enable driving of heavy loads (-15mA IOH, 64mA IOL). Conforms to JEDEC standard 18 for quality and reliability assurance.

Power-off disables outputs allow safe live insertion or removal. Wide operating temperature range supports versatile industrial and commercial applications. Compact physical dimensions for space optimization in circuit boards.

This bus transceiver is widely used in industrial, laboratory, and commercial electronic systems requiring reliable data bus communication and robust switching capabilities. Choose from a broad range of electronic components at EnvMart to complement your industrial and electronic system design projects.

Explore more products in our Bus Transceivers category.
