STMicroelectronics Operational Amplifier 880 kHz Gain Bandwidth, 5-Pin SOT-23, 1.5-5.5V TSV631AILT

Free Delivery in India | Lowest Global Shipping Charges

STMicroelectronics Operational Amplifier 880 kHz Gain Bandwidth, 5-Pin SOT-23, 1.5-5.5V TSV631AILT

Name: STMicroelectronics Operational Amplifier 880 kHz Gain Bandwidth, 5-Pin SOT-23, 1.5-5.5V TSV631AILT
Brand: STMicroelectronics
SKU: 319993
Price: 1.05 USD
Availability: InStock



Category Operational Amplifier Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Brand	STMicroelectronics
Height	1.3mm
Length	3mm
Model	TSV631AILT
Width	1.75mm
Mount Type	Surface
Series	TSV631A
Output Current	63mA
Maximum Operating Temperature	125°C
Package Type	SOT-23
Minimum Operating Temperature	-40°C
Number Of Channels	1
Standards/Approvals	RoHS
Pin Count	5
Automotive Standard	AEC-Q100
Maximum Supply Voltage	5.5V
Minimum Supply Voltage	1.5V
GBP - Gain Bandwidth Product	880kHz
Input Bias Current	100 pA
Vos - Input Offset Voltage	0.5 mV
Slew Rate	0.34V/μs

Key Features

The amplifier features rail-to-rail input and output capability for maximized dynamic range.
It delivers a low input bias current of 100 pA and low offset voltage of 0.5 mV for precise signal amplification.
Designed for low power consumption, it operates at 60 µA current at 5 V supply ensuring battery-friendly performance.
Operating temperature range from -40°C to 125°C ensures industrial reliability.
The device is suitable for sensor interface, portable electronics, and active filter circuits.
Its compact SOT-23 footprint enables small form factor designs.
The amplifier is unity gain stable with capacitive loads up to 100 pF.
Compliant with RoHS and automotive AEC-Q100 standards.

Product Description

STMicroelectronics TSV631AILT is a high-performance single operational amplifier designed to provide precision signal processing in compact 5-pin SOT-23 packages. Featuring a gain bandwidth product of 880 kHz and operating voltage range from 1.5 V to 5.5 V, this amplifier excels in low voltage, low power applications particularly suitable for battery-powered devices.

It offers rail-to-rail input and output stages that maximize dynamic range, alongside an input bias current as low as 100 pA and an input offset voltage of just 0.5 mV. The device consumes just 60 µA at 5 V, balancing power consumption with speed efficiently.

With industrial temperature ratings from -40°C to 125°C and automotive qualification per AEC-Q100, the TSV631AILT is reliable under harsh environmental conditions. It is unity gain stable with capacitive loads of up to 100 pF, making it ideal for sensor interfaces, portable instrumentation, and active filtering circuits.

The compact 3 mm length, 1.75 mm width, and 1.3 mm height SOT-23 surface mount package facilitates space-saving PCB designs in electronics manufacturing and embedded systems. The amplifier supports a single channel configuration with 5 pins.

Output current capability of 63 mA suits drive requirements for various circuit loads. RoHS compliant for environmentally safe usage. Series: TSV631A offering consistent performance parameters across devices. Common applications include industrial instrumentation, low power sensor signal conditioning, automotive electronics, and portable consumer devices.
