Panasonic PCB Power Relay 5V DC Coil 8A Switching Current SPST ST1-DC5V-F

Panasonic ST1-DC5V-F PCB Power Relay features a 5V DC coil voltage combined with an 8A switching current, offering reliable SPST (Single Pole Single Throw) contact configuration. This relay is engineered for electronic and electrical applications that require precise and stable switching control in compact PCB mount formats.

It belongs to the ST series, ideal for inductive load switching such as lamp loads, motors, and other industrial devices. The sealed construction of the relay permits automatic washing while maintaining excellent protection against environmental factors and contaminants.

The compact form factor measuring 31 mm in length, 14 mm in width, and 11 mm in height allows easy integration on printed circuit boards with standard pin terminals. The contact material is silver alloy, ensuring low contact resistance of 30 milliohms and longevity under frequent switching operations.

Operating temperature ranges from -40°C to 60°C, making it suitable for diverse environments including industrial, HVAC, manufacturing, and automation control panels. Coil resistance stands at 105 ohms with a power consumption of 240 mW, making it energy efficient for continuous operation.

The relay supports switching power of 150 watts with an AC maximum voltage of 380V and DC maximum voltage of 250V, accommodating a wide range of control requirements. It is approved to meet UL, CSA, and VDE standards, certifying its compliance with international safety and quality norms.

Applications include use in industrial automation, electronic devices, HVAC systems, and other electrical control systems requiring reliable, low power control switching integrated directly on PCB.

This PCB mount power relay is designed for inductive load switching with a high switching capability. It features a sealed design allowing for automatic washing and enhanced durability. Compact dimensions of 31 mm length, 14 mm width, and 11 mm height enable versatile PCB integration.

The relay uses silver alloy contact material for low contact resistance and improved performance. Operating temperature range from -40°C to 60°C ensures stable operation in diverse environments. Complies with UL, CSA, and VDE standards for quality and safety assurance.

Suitable for industrial, automation, electrical control, and HVAC system applications. Coil resistance is 105 ohms with a coil power rating of 240 mW for efficient operation. Switching power rating of 150 W and can switch AC voltage up to 380 V or DC voltage up to 250 V.

Contact configuration is Single Pole Single Throw (SPST), suitable for on/off control circuits. Explore the wide range of Power Relays and contactors available at EnvMart to suit your industrial and electrical automation requirements.
