MaxLinear Line Transceiver, Differential, Inverting, 8-Pin SOIC SP3082EEN-L

The MaxLinear SP3082EEN-L is a high-performance line transceiver designed for differential and inverting signal applications in industrial and electronic systems. It is housed in an 8-pin Small Outline Integrated Circuit (SOIC) package, enabling compact and surface-mount integration.

This device supports a supply voltage range from 4.5 to 5.5 volts and operates efficiently with a low supply current of approximately 900 microamperes. It incorporates CMOS logic family technology providing robust and reliable data interface capabilities. The transceiver features a single differential channel with an inverting polarity design, suitable for RS-485 and RS-422 communication protocols.

Its maximum propagation delay of 2.6 milliseconds under typical capacitive load conditions ensures timely signal transmission across industrial networks. The device is engineered for operation in harsh environments with temperature tolerances from -40°C to 85°C, making it well suited for a wide range of industrial, HVAC, manufacturing, and communication systems.

The compact dimensions of length 4.9mm, width 3.9mm, and height 1.75mm support dense PCB layouts while maintaining signal integrity. This line transceiver can be employed in applications requiring differential line signaling and enhanced noise immunity. It does not carry automotive standards certification but is designed with reliability in mind.

Typical uses include industrial controls, RS-485 fieldbus systems, factory automation, instrumentation, and data acquisition where differential, inverting line drivers and receivers are needed.

This line transceiver operates on a supply voltage range of 4.5V to 5.5V. It features a single differential channel with inverting polarity. The device uses CMOS logic family technology and surface mounting. The maximum propagation delay time under capacitive load is 2.6 milliseconds.

Operating temperature range spans from -40°C up to 85°C. Compact package dimensions include 4.9mm length, 3.9mm width, and 1.75mm height. Supply current is low at about 900 microamperes to ensure energy-efficient operation.

Suitable for robust RS-485 and RS-422 data communication protocols. Ideal for industrial, manufacturing, and electronics applications requiring differential transceiver ICs. Package contains one 8-pin SOIC device ready for surface mount assembly.
