STMicroelectronics Current Sensing Amplifier Dual Channel Surface Mount MiniSO8 Package TSC200IST
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.75mm |
| Length | 4.9mm |
| Model | TSC200IST |
| Mount Type | Surface |
| Maximum Operating Temperature | 125°C |
| Package Type | MiniSO8 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Pin Count | 8 |
| Maximum Supply Voltage | 18V |
| Minimum Supply Voltage | 2.7V |
| Supply Current | 5mA |
| CMRR - Common Mode Rejection Ratio | 120dB |
| Amplification gain | 20 V/V |
Key Features
- The device operates with single or dual power supply ranging from 2.7 V to 18 V.
- It features a wide common mode voltage range from -16 to +80 V, suitable for high-side current sensing.
- Amplification gain of 20 V/V enables effective signal scaling from shunt resistors.
- Integrated 0.6 V internal voltage reference and open-drain comparator with latch facilitates threshold detection.
- Provides precise current measurement over industrial temperature range from -40°C to +125°C.
- Compact MiniSO8 package of 4.9 mm length and 1.75 mm height supports surface mount technology.
- Supply current consumption is low at approximately 5 mA to optimize power efficiency.
- Suitable for industrial, automotive, power management, and electronic test equipment applications.
Product Description
The STMicroelectronics TSC200IST current sensing amplifier is a precision dual-channel device designed to deliver analog voltage output proportional to sensed current via a shunt resistor. It operates reliably with supply voltages from 2.7 V up to 18 V and handles a broad common mode voltage range from -16 V to +80 V, making it ideal for high-side current sensing applications.
This amplifier integrates an internal 0.6 V voltage reference and an open-drain comparator with latch function, enabling programmable threshold detection through an external resistor divider. The device provides an amplification gain of 20 V/V to convert small differential voltages into measurable analog outputs.
Packaged in a compact 8-pin MiniSO8 surface mount form factor, the TSC200IST occupies minimal PCB space, with package dimensions of 4.9 mm length by 1.75 mm height. It consumes a low supply current of 5 mA to maintain energy efficiency. Its robust industrial temperature rating from -40°C to +125°C ensures reliable operation in harsh environmental conditions.
This Current Sensing Amplifier is suitable for applications such as industrial automation, power supply monitoring, automotive current measurement, and electronic instrumentation where high accuracy and noise immunity are critical. Its high common mode rejection ratio (CMRR) of 120 dB guarantees resilience against voltage noise and interference.
Operates on single or dual supply voltages between 2.7 V and 18 V. Supports current sensing with common mode voltages from -16 V to +80 V. Integrated 0.6 V voltage reference and latched open-drain comparator enhance signal detection.
Amplification gain of 20 V/V amplifies shunt resistor signals effectively. Compact 8-pin MiniSO8 package supports surface mount assembly. Supply current is approximately 5 mA, enabling low power designs. Wide operating temperature range from -40°C to +125°C for industrial use.
High 120 dB CMRR for superior noise rejection in measurements. It facilitates enhanced control, protection, and diagnostics in power circuits and sensor systems. For more precision components and semiconductors, explore our comprehensive Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates with a supply voltage range from 2.7 V to 18 V.
The amplifier provides an amplification gain of 20 V/V, which allows for effective signal scaling from shunt resistors.
It supports a wide common mode voltage range from -16 V to +80 V, making it suitable for high-side current sensing applications.
The MiniSO8 package has a length of 4.9 mm and a height of 1.75 mm.
The maximum operating temperature is 125°C, allowing it to function reliably in harsh environments.
It consumes approximately 5 mA of supply current, optimizing power efficiency.
This current sensing amplifier is suitable for applications in industrial automation, power supply monitoring, automotive current measurement, and electronic instrumentation.
The TSC200IST features dual-channel operation, allowing for simultaneous current sensing on two channels.
The common mode rejection ratio (CMRR) is 120 dB, providing excellent noise rejection in measurements.
It supports surface mount technology, specifically in a MiniSO8 package.
Yes, it integrates a 0.6 V internal voltage reference and an open-drain comparator with latch for enhanced signal detection.
The minimum operating temperature is -40°C, ensuring reliable performance in low-temperature conditions.
