Microchip CAN Controller 1 Mbps, 28-Pin QFN, Surface Mount MCP25625T-E/ML
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 0.92mm |
| Length | 6mm |
| Model | MCP25625T-E/ML |
| Width | 6mm |
| Mount Type | Surface |
| Series | MCP25625 |
| Maximum Operating Temperature | 125°C |
| Package Type | QFN |
| Sub Type | CAN Controller |
| Minimum Operating Temperature | -40°C |
| Interface Type | CAN 2.0B |
| Pin Count | 28 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 2.7V |
| Supply Current | 10mA |
| Maximum Data Rate | 1Mbps |
| Number of Transceivers | 1 |
| Extended (E) | -40°C to +125°C |
Key Features
- Operates at a maximum data rate of 1 Mbps for robust CAN network performance.
- Integrated CAN transceiver and SPI interface enable direct connection to microcontrollers.
- Surface mount 28-Pin QFN package is ideal for compact design and durability.
- Supports operation from 2.7V to 5.5V supply, making it compatible with a wide range of MCU I/O voltages.
- Wide operating temperature range from -40°C to 125°C for demanding industrial environments.
- Features ESD protection and low standby current for enhanced reliability and energy efficiency.
- Pin count of 28 allows full-feature signal integration and flexible design options.
- Ideal for automotive, industrial, and embedded system applications requiring reliable CAN communication.
Product Description
Microchip MCP25625T-E/ML is an advanced high-speed CAN Controller IC with a 28-Pin QFN package, engineered for seamless communication between microcontrollers and Controller Area Networks (CAN). This interface IC is specifically designed to meet the needs of automotive, industrial, and embedded system applications that require robust, reliable CAN data transfer.
The MCP25625T-E/ML integrates a stand-alone CAN 2.0B controller with a built-in CAN transceiver and SPI interface, eliminating the need for external level shifters and simplifying system design. Capable of operating at data rates up to 1 Mbps, it ensures rapid and stable CAN communication across complex networks.
With surface mount configuration and a compact 6x6 mm QFN package, the IC is suitable for space-constrained designs and provides secure mounting and excellent thermal performance. The 28-pin layout offers comprehensive connectivity to support diverse applications, while ESD protection and low standby current optimize reliability and power efficiency.
Key technical features include a supply voltage range from 2.7V to 5.5V, wide operating temperature (-40°C to 125°C), and compatibility with SPI clock speeds up to 10 MHz. The MCP25625T-E/ML's small footprint and robust specification make it a preferred choice for automotive ECUs, industrial controllers, and embedded systems where high-speed CAN communication is essential.
Applications extend across automotive body electronics, industrial automation, commercial vehicle networking, and embedded control systems. The device is implemented in environments demanding reliable, energy-efficient, and high-integrity data communication.
Explore more CAN Interface ICs and Microchip products on EnvMart to find optimal solutions for automotive and industrial networking.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The MCP25625T-E/ML operates at a maximum data rate of 1 Mbps, ensuring robust CAN network performance.
This model supports a supply voltage range from 2.7V to 5.5V, making it compatible with a wide range of microcontroller I/O voltages.
It has a wide operating temperature range from -40°C to 125°C, suitable for demanding industrial environments.
The MCP25625T-E/ML comes in a surface mount 28-Pin QFN package, which is ideal for compact designs.
This unit features a pin count of 28, allowing for full-feature signal integration and flexible design options.
It supports the CAN 2.0B interface type, which is essential for reliable CAN communication.
The height of this model is 0.92 mm, making it suitable for space-constrained applications.
The MCP25625T-E/ML has a supply current of 10 mA, optimizing energy efficiency during operation.
It is ideal for automotive, industrial, and embedded system applications requiring reliable CAN communication.
Yes, this model features ESD protection, enhancing reliability in various environments.
The maximum operating temperature for the MCP25625T-E/ML is 125°C, suitable for high-temperature applications.
This model has a length and width of 6 mm each, contributing to its compact design.
