Power Integrations High Voltage Switcher 10 A, 24V, 3V Output, 24-Pin Surface Mount InSOP-24D Package INN4074C-H182-TL

Power Integrations INN4074C-H182-TL is a high voltage switcher integrated circuit designed for efficient flyback power converters. This device features a maximum output current of 10 A and output voltage of 24 V, housed in a compact 24-pin InSOP-24D surface mount package. Its wide input voltage range, from a minimum of 85 V to a maximum of 264 V, allows versatile application in various AC-DC power conversion contexts.

The IC operates at a switching frequency up to 140 kHz, which significantly reduces transformer size and overall design footprint. It includes primary and secondary controllers, along with safety-rated feedback, integrated within a single IC, simplifying design complexity while improving reliability.

This model incorporates multiple protection features, including output overvoltage protection, overcurrent limiting, and overtemperature shutdown, ensuring device and circuit safety. The low supply current of 2.7 mA enhances energy efficiency, making it suitable for modern power supplies.

Operating from -40°C to 150°C, the INN4074C-H182-TL accommodates demanding industrial, commercial, and consumer electronics environments. Its flyback topology usage and synchronous rectification capability offer improved power conversion efficiency, aligning with advanced power management system requirements.

The switcher's small package dimensions of 10.8 mm height, 9.4 mm length, and 1.6 mm width contribute to compact device layouts. It complies with no specific approvals but meets Power Integrations' quality and reliability standards, enhancing its suitability for power management IC applications.

Supports a maximum input voltage of 264 V for flexible power supply designs. Operates with a switching frequency up to 140 kHz to reduce transformer size. Integrates primary and secondary controllers and safety-rated feedback in one IC.

Includes multiple protection features such as overvoltage, overcurrent, and overtemperature shutdown. Suitable for flyback topology power converters requiring compact form factors. Wide operating temperature range from -40°C to 150°C enables industrial and commercial applications.

Low supply current of 2.7 mA for energy-efficient operation. Designed in the InnoSwitch4-CZ series with synchronous rectification driver for enhanced efficiency.

This high voltage switcher IC by Power Integrations fits a wide range of industrial, laboratory, and commercial energy management applications, including AC-DC converters for appliance, lighting, and communication equipment power supplies. Its compact form factor enables PCB space-saving designs without compromising performance.
