Glenair Copper Alloy Straight 10 Way Box Mount MIL Spec Circular Connector Female Brown, Male Contacts, Shell IPT02A12-10P

Free Delivery in India | Lowest Global Shipping Charges

Glenair Copper Alloy Straight 10 Way Box Mount MIL Spec Circular Connector Female Brown, Male Contacts, Shell IPT02A12-10P

Name: Glenair Copper Alloy Straight 10 Way Box Mount MIL Spec Circular Connector Female Brown, Male Contacts, Shell IPT02A12-10P
Brand: Glenair
SKU: 291987
Price: 110.42 USD
Availability: InStock



Category Mil Spec Circular Connector Brand Glenair Condition New

Specifications

Country of Origin	Italy
Voltage	600, 700V ac
Brand	Glenair
Colour	Brown
Orientation	Straight
Current	7.5A
Model	IPT02A12-10P
Mount Type	Box Mount
Contact Material	Copper Alloy
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Contact Plating	Gold over Nickel
Number of Contacts	10
Contact Gender	Male
Connector Gender	Female
Shell Size	12
Military Standard	MIL-DTL-26482
Mating Type	Bayonet
Connector Size	Standard
Shell Plating	Olive Drab Cadmium

Key Features

The connector is made of durable copper alloy with gold over nickel plating for enhanced contact performance.
It supports a voltage rating of 600 to 700V AC and current up to 7.5A, suitable for demanding electronics applications.
The shell size is 12 with olive drab cadmium plating, providing corrosion resistance and robust mechanical protection.
This connector operates effectively between -55°C and 125°C, making it suited for harsh environments.
The termination type is solder, ensuring secure wiring connections.
It uses a bayonet mating type with industry-standard MIL-DTL-26482 specifications compliance.
The connector has a standard connector size and a straight orientation for easy panel mounting.
Designed for box mount installation, it offers stable and secure mounting on equipment panels.

Product Description

The Glenair IPT02A12-10P is a high-quality MIL Spec Circular Connector designed for industrial and military applications, offering reliable electrical connections with 10 male contacts and a female connector gender. Constructed from copper alloy with gold over nickel plating on contacts and olive drab cadmium on the shell, it ensures excellent conductivity and resistance to corrosion.

It supports AC voltages of 600 to 700V and a current rating of 7.5A, capable of withstanding demanding electrical loads. The shell size 12 design with straight orientation and box mount type makes it ideal for panel installations, providing secure and stable connections.

This connector complies with MIL-DTL-26482 military standards, featuring a bayonet mating type for quick and secure coupling. Designed to operate reliably within a temperature range of -55°C to 125°C, it is well-suited for harsh environments encountered in industrial, aerospace, and defense sectors.

Solder termination type ensures firm electrical connections while the standard connector size maintains compatibility with a variety of systems. The brown color provides easy visual identification and differentiation in complex setups.

The connector is crafted from copper alloy with gold over nickel plating for superior electrical performance and durability. Supports voltage ratings of 600 and 700V AC and a current of 7.5 amperes for robust power handling.

The shell is plated with olive drab cadmium to resist corrosion and physical wear. Temperature range from -55°C minimum to 125°C maximum allows for versatile industrial use. Bayonet mating type ensures fast and secure attachment between connector components.

Straight orientation provides straightforward panel mounting with a box mount configuration. Conforms to MIL-DTL-26482 military standard for certified quality and reliability.

This connector is suitable for applications in electronics manufacturing, aerospace, defense, industrial machinery, and other sectors requiring high-reliability electrical connectors. Its rugged construction and compliance with military specifications ensure dependable performance in extreme conditions.

EnvMart offers this Glenair Mil Spec Circular Connector as part of the Connectors category, providing customers with trusted components for precision electronic and power connections.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This connector supports a voltage rating of 600 to 700V AC and a current rating of 7.5A, making it suitable for demanding electronics applications.

It operates effectively within a temperature range of -55°C to 125°C, making it suitable for harsh environments.

The connector uses a solder termination type, ensuring secure wiring connections.

The shell size is 12, and it features olive drab cadmium plating for corrosion resistance and mechanical protection.

This model has 10 male contacts and features a female connector gender.

It utilizes a bayonet mating type, which allows for quick and secure coupling between components.

Yes, it complies with the MIL-DTL-26482 military standard, ensuring it meets specific quality and reliability requirements.

This connector has a straight orientation and is designed for box mount installation, providing stable and secure mounting on equipment panels.

The contacts are made of copper alloy with gold over nickel plating for enhanced contact performance.

The connector is brown, which aids in visual identification in complex setups.

The country of origin for this connector is Italy.

It is suitable for applications in electronics manufacturing, aerospace, defense, and industrial machinery, requiring high-reliability electrical connections.
