STMicroelectronics 2 MB Serial-I2C EEPROM 900 ns 8-Pin SO-8 M24M02-DWMN3TP/K
Specifications
| Country of Origin | China |
|---|---|
| Brand | STMicroelectronics |
| Height | 6.2mm |
| Length | 5mm |
| Model | M24M02-DWMN3TP/K |
| Width | 169mm |
| Mount Type | Surface |
| Series | M24M02-A125 |
| Maximum Operating Temperature | 125°C |
| Package Type | SO-8 |
| Minimum Operating Temperature | -40°C |
| Memory size | 2MB |
| Interface Type | Serial-I2C |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 2.5V |
| Supply Current | 2mA |
| Maximum Clock Frequency | 1MHz |
| Organisation | 256k x 8 Bit |
| Number of Bits per Word | 8 |
| Maximum Random Access Time | 900ns |
| Number of Words | 256K |
Key Features
- Automotive grade EEPROM operating up to 125 °C.
- Serial-I2C interface with maximum clock frequency of 1 MHz.
- Memory organized as 256 K x 8 bits, byte-alterable with 1024 pages of 256 bytes.
- Embedded Error Correction Code logic for improved data integrity.
- Additional 256-byte Identification Page with lockable read-only mode.
- Wide supply voltage range from 2.5 V to 5.5 V.
- Operating temperature range from -40 °C to 125 °C.
- Low supply current of 2 mA ensuring efficient power consumption.
Product Description
STMicroelectronics M24M02-DWMN3TP/K is a 2 MB (2 Mbit) serial EEPROM designed for automotive applications operating up to 125 °C. It features a fast maximum random access time of 900 ns and utilizes a Serial-I2C interface compatible with clock speeds up to 1 MHz.
The EEPROM memory is organized as 256 K x 8 bits, allowing byte-alterable access with 1024 pages of 256 bytes. It is based on advanced true EEPROM technology, providing reliable electrically erasable and programmable memory.
An embedded Error Correction Code (ECC) logic significantly enhances data integrity, reducing the risk of data corruption during operations. The device also includes an additional Identification Page of 256 bytes, which can be permanently locked in read-only mode for storing sensitive application parameters or device identification data.
The device supports a wide supply voltage range from 2.5 V to 5.5 V and operates reliably between -40 °C and 125 °C, suitable for harsh automotive environments. It consumes a low supply current of 2 mA, optimizing power efficiency.
The M24M02-DWMN3TP/K comes in a compact 8-pin SO-8 surface mount package, facilitating easy integration into compact PCB designs.
This EEPROM is ideal for industrial and automotive applications requiring robust memory solutions with fast access times, high data integrity, and extended temperature tolerance, including control systems, embedded memory, and parameter storage.
Automotive grade EEPROM operating up to 125 °C. Serial-I2C interface with maximum clock frequency of 1 MHz. Memory organized as 256 K x 8 bits, byte-alterable with 1024 pages of 256 bytes. Embedded Error Correction Code logic for improved data integrity.
Additional 256-byte Identification Page with lockable read-only mode. Wide supply voltage range from 2.5 V to 5.5 V. Operating temperature range from -40 °C to 125 °C. Low supply current of 2 mA ensuring efficient power consumption.
Compact SO-8 surface mount package with 8 pins. Explore more semiconductor memory products from STMicroelectronics and other brands at EnvMart for your electronic design and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating temperature of this EEPROM is 125 °C, making it suitable for automotive applications.
The memory is organized as 256 K x 8 bits, allowing for byte-alterable access with 1024 pages of 256 bytes each.
It supports a wide supply voltage range from 2.5 V to 5.5 V, accommodating various application requirements.
This EEPROM utilizes a Serial-I2C interface, compatible with clock speeds up to 1 MHz.
The maximum random access time is 900 ns, allowing for fast data retrieval.
The supply current is 2 mA, which helps to ensure efficient power consumption.
It comes in a compact 8-pin SO-8 surface mount package, facilitating easy integration into PCB designs.
This model complies with the AEC-Q100 automotive standard, ensuring reliability in automotive applications.
Yes, it includes embedded Error Correction Code (ECC) logic to improve data integrity and reduce corruption risks.
It has an additional 256-byte Identification Page that can be permanently locked in read-only mode for sensitive data storage.
The dimensions of this EEPROM are 5 mm in length, 6.2 mm in height, and 1.69 mm in width.
It is ideal for industrial and automotive applications requiring robust memory solutions, such as control systems and parameter storage.
