Sifam Tinsley 3-Channel Graphical Chart Recorder Current Humidity Temperature Resistance Voltage N30B-102900U0

Sifam Tinsley N30B-102900U0 3-Channel Graphical Chart Recorder offers precise data acquisition and recording for current, humidity, temperature, resistance, and voltage parameters with high accuracy of 0.2%. Designed for industrial, laboratory, HVAC, manufacturing, and environmental monitoring applications, this digital panel recorder provides reliable multi-parameter measurement and logging capabilities.

The device incorporates two RS485 interfaces with Modbus RTU protocol supporting master and slave modes, enabling seamless integration with various devices. Its 14mm 5-digit tri-color display is programmable across three display value ranges, facilitating easy interpretation of measurement data. Individual characteristic rescaling through 21-point settings allows for customizable measurement scales.

This instrument provides extensive data storage with internal memory capable of holding 350,064 records and supports data archiving on MMC/SD cards with capacities up to 4GB. Data can also be archived to a PC-based MySQL database. It outputs analogue signals via 0-10V or 0/4-20mA converters to interface with control systems or other equipment.

Additional features include real-time clock with automatic daylight saving adjustments and notification of MMC/SD card capacity exceedance, ensuring uninterrupted data logging. Despite its compact size of 96mm length, 93mm width, and 48mm height, it is engineered for durability and ease of installation.

Graphical chart type ensures visual data representation with 0.2% measurement accuracy. Three measurement channels support simultaneous monitoring of multiple parameters. Measurement parameters include current, humidity, temperature, resistance, and voltage.

Two RS485 interfaces with Modbus RTU protocol enable versatile device communication. Internal memory and external MMC/SD card support facilitate extensive data storage and archiving. Analogue output conversion for integration with control and monitoring systems.

RTC with daylight saving time automatic adjustment enhances time accuracy. Lightweight and compact dimensions suitable for panel mounting. Ideal for industrial, laboratory, HVAC, manufacturing, water treatment, and commercial environments.

This chart recorder is an essential instrument in measuring and recording multiple electrical and environmental parameters for various industrial and laboratory applications. Explore more advanced measuring and testing instruments in the Chart Recorders category on EnvMart.
