Maxim Integrated 8-Channel 10-Bit 133 ksps Analog-to-Digital Converter 20-Pin SO MAX192BCWP+
Specifications
| Country of Origin | United States |
|---|---|
| Resolution | 10 bit |
| Brand | Maxim Integrated |
| Height | 2.64mm |
| Length | 13.01mm |
| Model | MAX192BCWP+ |
| Mount Type | Surface |
| Sampling rate | 133ksps |
| Series | MAX192 |
| Input Type | Analogue |
| Maximum Operating Temperature | 70°C |
| Package Type | SO |
| Minimum Operating Temperature | 0°C |
| Interface Type | QSPI, Microwire, SPI |
| Architecture | SAR |
| Pin Count | 20 |
| Minimum Supply Voltage | 5V |
| Number of ADCs | 8 |
Key Features
- Employs successive approximation register (SAR) architecture for efficient conversion.
- Supports 8 individual ADC channels facilitating simultaneous multi-point monitoring.
- Provides 10-bit resolution enabling accurate analog signal digitization.
- Operates with low power consumption at a 5 V supply voltage.
- Can interface with QSPI, Microwire, and SPI digital communication protocols.
- Rated for operating temperatures ranging from 0°C to 70°C ensuring reliable industrial performance.
- Compact 20-pin small-outline (SO) surface-mount package with dimensions 13.01 mm length and 2.64 mm height.
- Designed and manufactured in the United States, meeting quality standards for semiconductor devices.
Product Description
Maxim Integrated MAX192BCWP+ is a high-performance analog-to-digital converter (ADC) featuring eight channels and 10-bit resolution. The device employs successive approximation register (SAR) architecture for fast and accurate analog signal conversion at a sampling rate of 133 thousand samples per second (ksps). Its surface-mount 20-pin small-outline (SO) package enables easy integration into compact PCB designs.
The MAX192BCWP+ ADC supports multiple digital interface protocols including QSPI, Microwire, and SPI, facilitating flexible communication with various microcontrollers and DSPs. Its operating voltage of 5 V and a temperature range from 0°C to 70°C make it suitable for a wide range of industrial and commercial applications.
This ADC is ideal for applications requiring multi-channel analog input monitoring such as industrial instrumentation, data acquisition systems, and embedded control units. The compact package size of 13.01 mm length and 2.64 mm height supports space-constrained electronic assemblies.
Manufactured in the United States, the MAX192BCWP+ ensures reliable quality and consistent performance across demanding operating conditions. It is part of the MAX192 series known for robust analog-to-digital conversion solutions.
Employs SAR architecture for efficient analog-to-digital conversion. Provides 8 ADC channels to monitor multiple analog signals. Delivers 10-bit resolution for precise digitization. Supports QSPI, Microwire, and SPI digital interfaces.
Compatible with 5 V supply voltage and 0°C to 70°C operating temperatures. Packaged in a 20-pin SO surface-mount format for compact PCB integration. Manufactured in the United States ensuring high quality and reliability.
This Maxim Integrated ADC is well suited for industrial, laboratory, embedded electronics, and signal processing applications where multi-channel analog input conversion is essential. Explore more high-quality semiconductor and ADC components at EnvMart for your next design and manufacturing project.
Explore more products in our Analogue to Digital Converter category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The MAX192BCWP+ ADC provides a resolution of 10 bits, enabling precise digitization of analog signals.
This model supports 8 individual ADC channels, allowing for simultaneous multi-point monitoring of analog signals.
The maximum sampling rate of the MAX192BCWP+ is 133 ksps (thousand samples per second).
It supports QSPI, Microwire, and SPI digital communication protocols, providing flexibility in interfacing with various microcontrollers and DSPs.
This unit operates with a minimum supply voltage of 5 V.
The ADC is rated for operating temperatures ranging from 0°C to 70°C, making it suitable for industrial applications.
The package dimensions are 13.01 mm in length and 2.64 mm in height, designed for compact PCB integration.
It employs a successive approximation register (SAR) architecture for efficient analog-to-digital conversion.
The MAX192BCWP+ accepts analog input signals for conversion to digital format.
This ADC is suitable for applications such as industrial instrumentation, data acquisition systems, and embedded control units that require multi-channel analog input monitoring.
The MAX192BCWP+ features a 20-pin configuration, suitable for surface-mount installation.
This model is designed and manufactured in the United States, ensuring compliance with quality standards for semiconductor devices.
