STMicroelectronics STM32F072C8T6 32-bit ARM Cortex M0 Microcontroller 48 MHz 64kB Flash 48-Pin LQFP

STMicroelectronics STM32F072C8T6 is a 32-bit ARM Cortex M0 microcontroller operating at a maximum clock frequency of 48 MHz with 64kB of flash memory. This device is designed for a broad spectrum of embedded applications requiring efficient processing performance with low power consumption.

The microcontroller is equipped with 16kB SRAM and includes numerous integrated peripherals such as one USB full-speed device that operates crystal-less, one CAN bus, and multiple communication interfaces including I2C, SPI/I2S, HDMI CEC, and USART ports. The device supports 13 channels of 12-bit ADC, a 12-bit DAC with two channels, and analogue comparators to support advanced analog input processing.

Package specifications include a 48-pin LQFP surface-mount form factor with compact dimensions of 7.2 mm by 7.2 mm and a height of 1.45 mm. The device supports operating voltages from 2.0 to 3.6 volts and operates reliably within a temperature range of -40°C to +85°C, suitable for industrial and automotive environments.

The STM32F072C8T6 microcontroller supports multiple timers including seven 16-bit timers, one 32-bit timer, and an advanced-control PWM timer, enabling complex timing and control applications. Its power consumption is efficient with a maximum dissipation of 370 mW, making it ideal for handheld and battery-powered devices.

This microcontroller is well suited for use in application control, user interfaces, handheld devices, audio/video receivers and digital TVs, industrial automation, PLCs, inverters, printers, scanners, alarm systems, video intercoms, and HVAC control systems.

Features ARM Cortex M0 32-bit RISC core operating up to 48 MHz. 64kB Flash memory and 16kB SRAM for program and data storage. 48-pin LQFP surface-mount package with compact dimensions. Integrated USB full-speed device without crystal, CAN bus, and multiple communication interfaces.

Includes 13 x 12-bit ADC channels and 1 x 12-bit DAC with two outputs. Operates from 2.0 V to 3.6 V supply voltage range. Wide operating temperature range from -40°C to 85°C. Includes multiple timers and advanced PWM capabilities.
