STMicroelectronics Operational Amplifier, 8 MHz Gain Bandwidth, 4-Channel, 14-Pin Surface Mount SO Package TSV914AIDT
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.65mm |
| Length | 8.75mm |
| Model | TSV914AIDT |
| Width | 4mm |
| Mount Type | Surface |
| Series | TSV914 |
| Output Current | 35mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SO |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 4 |
| Standards/Approvals | RoHS |
| Pin Count | 14 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 2.5V |
| GBP - Gain Bandwidth Product | 8MHz |
| Input Bias Current | 100 pA |
| Vos - Input Offset Voltage | 7.5 mV |
| Slew Rate | 4.5V/μs |
| Low input offset voltage | 1.5 mV max (A grade) |
Key Features
- Features a 4-channel configuration for versatile applications.
- Operates with supply voltage range from 2.5 V to 5.5 V.
- Provides rail-to-rail input and output for full signal range handling.
- Consists of ultra-low input bias current ideal for sensor interfaces.
- Offers high output current capability up to 35 mA.
- Designed for battery-powered and portable industrial equipment.
- Includes ESD internal protection of 5 kV and latch-up immunity for reliability.
- Compliance with RoHS and automotive standard AEC-Q100.
Product Description
STMicroelectronics TSV914AIDT operational amplifier is a high-performance low voltage device optimized for industrial, automotive, and portable electronic applications. It provides a gain bandwidth product of 8 MHz while consuming only around 1.1 mA maximum at 5 V supply, making it ideal for efficient power-sensitive designs.
The device features a 4-channel architecture with 14 pins in a surface mount Small Outline (SO) package. It supports a wide input and output voltage range with rail-to-rail capability, ensuring accurate signal processing across the full voltage swing. The ultra-low input bias current of approximately 1 pA effectively minimizes errors in sensor interface circuits and active filtering.
Robust design elements include a maximum output current of 35 mA and wide operating temperature range from -40°C to 125°C, enabling reliable operation in harsh automotive and industrial environments. The TSV914 series conforms to the automotive AEC-Q100 standard and RoHS directives, certifying it against quality and environmental regulations.
Four independent amplifiers integrated in one package provide compact and efficient design solutions. Typical low power consumption of 820 µA supports battery-supplied and portable devices. High slew rate of 4.5 V/µs ensures fast transient response for dynamic signal applications.
Protection features include internal ESD protection rated at 5 kV and latch-up immunity for enhanced device robustness. Pin count of 14 enables integrating multiple channels while maintaining a small footprint of 8.75 mm by 4 mm by 1.65 mm.
This Operational Amplifier series is intended for use in sensor interfaces, active filtering, battery-powered devices, telecommunications, and automotive electronics where precise amplification and low noise are imperative.
Explore more semiconductor Amplifiers at EnvMart for industrial electronics, automotive systems, and laboratory-grade instrumentation.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 8 MHz, making it suitable for various applications requiring efficient signal processing.
It operates with a supply voltage range from 2.5 V to 5.5 V, allowing flexibility in various circuit designs.
This operational amplifier features a 4-channel configuration, providing multiple amplification options in a single package.
The maximum output current capability is 35 mA, which supports a variety of load requirements in applications.
The dimensions of this model are 8.75 mm in length, 4 mm in width, and 1.65 mm in height, making it compact for surface mount applications.
It can operate within a temperature range of -40°C to 125°C, suitable for harsh environments.
Yes, it features rail-to-rail input and output, ensuring full signal range handling for accurate processing.
The slew rate is 4.5 V/µs, which allows for fast transient response in dynamic signal applications.
It comes in a 14-pin Small Outline (SO) package, designed for surface mounting.
The input bias current is approximately 100 pA, which is beneficial for minimizing errors in sensor interfaces.
Yes, it complies with RoHS directives and the automotive standard AEC-Q100, ensuring quality and environmental compliance.
It is intended for use in sensor interfaces, active filtering, battery-powered devices, telecommunications, and automotive electronics.
