STMicroelectronics Operational Amplifier Precision Rail-to-Rail 3 MHz Gain Bandwidth, 12 V, 5-Pin SOT-23 Package TS9511ILT
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.3mm |
| Length | 3mm |
| Model | TS9511ILT |
| Width | 1.75mm |
| Mount Type | Surface |
| Series | TS9511 |
| Output Current | 20mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Standards/Approvals | RoHS |
| Pin Count | 5 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 12V |
| Minimum Supply Voltage | 2.7V |
| GBP - Gain Bandwidth Product | 3MHz |
| Input Bias Current | 150 nA |
| Slew Rate | 1V/μs |
| Input Offset Current | 80 nA |
| Wide supply voltage range | 2.7 V to 12 V |
| Good precision | 800 μV max |
| micro package | SOT23-5 |
Key Features
- This amplifier features a low input bias current of 150 nA enhancing signal accuracy.
- It operates across a temperature range of -40°C to 125°C for robust industrial applications.
- The device is packaged in a compact SOT-23 5-pin surface mount format ideal for space-constrained designs.
- It provides a slew rate of 1 V/μs ensuring fast response to input signals.
- The output current capability is up to 20 mA supporting various load conditions.
- Compliance with RoHS and AEC-Q100 standards ensures environmental and automotive quality standards.
- Input offset voltage is tightly controlled at 1500 μV max for precision performance.
- The TS9511ILt is suitable for automotive, industrial, consumer, and computer applications requiring reliable amplification.
Product Description
STMicroelectronics TS9511ILT is a single-channel precision operational amplifier that delivers high-performance rail-to-rail input and output capability with a gain bandwidth product (GBP) of 3 MHz. It supports a low supply current and wide voltage range between 2.7 V and 12 V, fitting a broad scope of electronic circuit designs.
Housed in a small SOT-23 5-pin surface mount package, the amplifier occupies minimal PCB space making it ideal for compact and portable devices. Its wide operating temperature range from -40°C up to 125°C ensures reliable operation in harsh environments such as automotive and industrial systems.
The device offers excellent precision with an input offset voltage maximum of 1500 μV and an input offset current of 80 nA. It also maintains a slew rate of 1 V/μs and an output drive capability of 20 mA, making it suitable for fast, accurate signal conditioning and amplification tasks.
Key features include rail-to-rail input/output functionality, low quiescent current of 900 μA at 3 V supply voltage, and high supply voltage rejection ratio of 85 dB, guaranteeing stable performance under varying power supply conditions.
Low input bias current of 150 nA for precision signal amplification. Compact micro package SOT23-5 for space-saving PCB layouts. Wide supply voltage range supporting 2.7 V to 12 V operation. High-speed operation with 3 MHz gain bandwidth product.
Compliant with RoHS and automotive AEC-Q100 standards. Operating temperature range from -40°C to 125°C catering to automotive and industrial requirements. Output current up to 20 mA for various load drives. Input offset voltage max 1500 μV supporting high accuracy.
This amplifier is well-suited for automotive, industrial, consumer electronics, and computing applications where precision amplification and low power consumption are essential. Its robust package and specifications make it a reliable choice for demanding environments.
Explore the Electronics & Electricals category on EnvMart for more high-quality Operational Amplifiers and precision components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The TS9511ILT has a gain bandwidth product (GBP) of 3 MHz, which supports high-speed operation for various applications.
This model can provide an output current of up to 20 mA, making it suitable for driving various loads.
The operational amplifier operates within a temperature range of -40°C to 125°C, allowing it to function reliably in harsh environments.
The TS9511ILT supports a wide supply voltage range from 2.7 V to 12 V, accommodating various circuit designs.
The SOT-23 package measures 3 mm in length, 1.75 mm in width, and 1.3 mm in height, making it compact for space-constrained applications.
The input offset voltage is tightly controlled at a maximum of 1500 μV, ensuring high precision in signal amplification.
Yes, it complies with RoHS and AEC-Q100 standards, ensuring it meets environmental and automotive quality requirements.
This operational amplifier has a slew rate of 1 V/μs, which allows for fast response to changing input signals.
The input bias current for this model is 150 nA, which enhances signal accuracy during amplification.
This operational amplifier is a single-channel device, designed for applications requiring precise amplification.
The TS9511ILT is designed for surface mounting, specifically in a compact SOT-23 package.
This operational amplifier is suitable for automotive, industrial, consumer electronics, and computing applications that require reliable amplification.
