C & K Rotary Coded DIP Switch Surface Mount Side Actuated BPA04SBR
Specifications
| Country of Origin | India |
|---|---|
| Brand | C & K |
| Model | BPA04SBR |
| Mount Type | Surface Mount |
| Actuator Type | Side |
| Switch Contact Rating | 100 mA @ 5 V dc / 25 mA @ 24 V dc |
| Electrical Life | 1000 cycles minimum |
Key Features
- Switch contact rating is 100 mA at 5 V dc and 25 mA at 24 V dc.
- Designed for surface mount applications with side actuation.
- Equipped with a high pressure contact system that improves reliability.
- Electrical life rated at a minimum of 1000 cycles ensuring durability.
- Compact dual-in-line package suitable for automated manufacturing.
- Ideal for automation, electrical, and industrial control systems.
- Compact design reduces PCB footprint and simplifies assembly.
Product Description
C & K BPA04SBR Rotary Coded DIP Switch is a surface mount side actuated switch designed for precision switching applications requiring compact size and reliable operation. It features a high pressure contact system that eliminates the need for a tape seal during washing processes, enhancing manufacturing efficiency and product reliability.
This switch has a contact rating of 100 mA at 5 V dc and 25 mA at 24 V dc, making it suitable for low current control signals. It offers a minimum electrical life of 1000 cycles, ensuring durability in repetitive switching applications. The dual-in-line packaging allows automated insertion for improved production throughput.
The side actuation mechanism provides ergonomic operation and saves PCB space compared to traditional top actuated switches. Its surface mount construction makes it an excellent choice in modern electronics manufacturing where compact and automated assembly is critical.
Typical industrial uses include electrical equipment control panels, automation systems, instrumentation, and embedded electronics requiring coded rotary switch functionality for configuration and settings.
C & K is known for high quality switch components suitable for commercial and industrial applications ranging from consumer devices to complex machine control. Switch contact rating of 100 mA @ 5 V dc and 25 mA @ 24 V dc.
Electrical life of minimum 1000 cycles for dependable operation. Side actuated full profile design for easy operation and compactness. Surface mount package optimized for automated assembly processes. No tape seal required for washing due to high pressure contact system.
Dual-in-line switch configuration supporting standard PCB layouts. Robust build quality suitable for demanding industrial applications. This product is part of EnvMart Electronics & Electricals category for Switches & Sockets, specifically Rotary Coded DIP Switches.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The switch contact rating is 100 mA at 5 V dc and 25 mA at 24 V dc.
It has an electrical life rated at a minimum of 1000 cycles, ensuring dependable operation in repetitive switching applications.
The BPA04SBR is designed for surface mount applications, making it suitable for modern electronics manufacturing.
The side actuation mechanism provides ergonomic operation and saves PCB space compared to traditional top actuated switches.
It is ideal for automation, electrical, and industrial control systems, as well as instrumentation and embedded electronics requiring coded rotary switch functionality.
The high pressure contact system eliminates the need for a tape seal during washing processes, enhancing manufacturing efficiency and product reliability.
The BPA04SBR features a compact dual-in-line package, which is optimized for automated insertion, improving production throughput.
Specific dimensions are not provided in the product details, but it is designed to be compact to reduce PCB footprint.
Yes, with a contact rating of 100 mA at 5 V dc and 25 mA at 24 V dc, it is suitable for low current control signals.
The switch is manufactured in India.
Yes, it is built with a robust quality suitable for demanding industrial applications.
The actuator type for the BPA04SBR is side, allowing for easy operation.
