Eaton Wirewound Shielded Surface Mount Inductor with Ferrite Core 15 μH ±20% 9.66 A IDC DR127-150-R
Specifications
| Country of Origin | China |
|---|---|
| Brand | Eaton |
| Height | 8mm |
| Length | 12.5mm |
| Model | DR127-150-R |
| Depth | 12.5mm |
| Packaging | Reel |
| Series | DR |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 15μH |
| Standards/Approvals | RoHS |
| Package/Case | 0127 |
| Maximum DC Current | 9.66A |
| Pin Count | 2 |
| Maximum DC Resistance | 24.7mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 100kHz |
| Inductor Construction | Wirewound |
Key Features
- Constructed with a ferrite core to ensure high efficiency and magnetic shielding.
- Designed for surface mount applications with a 0127 package case.
- Maximum operating temperature rated at 125°C for reliable performance.
- Offers low DC resistance of 24.7 mΩ to reduce power loss.
- Suitable for use in computers, portable devices, and DC-DC converters.
- Features a compact size with 12.5 mm length, 8 mm height, and 12.5 mm depth.
- Compliant with RoHS standards, ensuring environmental safety.
- Moulded and magnetically shielded construction minimizes interference.
Product Description
Eaton DR127-150-R wirewound shielded surface mount inductor features a ferrite core for enhanced magnetic performance, providing an inductance of 15 μH with a tolerance of ±20% and supporting a maximum DC current of 9.66 A. It is designed with a 0127 package case, suitable for surface mount technology in compact electronic assemblies.
This inductor exhibits a maximum operating temperature of 125°C, making it reliable under demanding thermal conditions. Its low DC resistance of 24.7 mΩ minimizes power losses, improving efficiency in circuit applications. The unit is moulded and magnetically shielded to reduce electromagnetic interference, ensuring signal integrity in sensitive electronic environments.
The product dimensions are 12.5 mm in length, 8 mm in height, and 12.5 mm in depth, making it suitable for space-constrained applications. Eaton's DR series inductors are widely used in computers, DVD players, portable devices, LCD panels, and power conversion circuits such as buck, boost, and forward converters, as well as resonant converters and noise filters.
Manufactured to RoHS standards, the DR127-150-R supports frequencies up to 100 kHz and features a 2-pin surface mount termination for easy PCB integration. Its ferrite core construction and magnetic shielding enhance performance stability and reduce EMI.
Constructed with a ferrite core to ensure high efficiency and magnetic shielding. Designed for surface mount applications with a 0127 package case. Maximum operating temperature rated at 125°C for reliable performance. Offers low DC resistance of 24.7 mΩ to reduce power loss.
Suitable for use in computers, portable devices, and DC-DC converters. Features a compact size with 12.5 mm length, 8 mm height, and 12.5 mm depth. Compliant with RoHS standards, ensuring environmental safety. Moulded and magnetically shielded construction minimizes interference.
Supports frequencies up to 100 kHz with 2-pin termination style.
This Eaton DR127-150-R inductor is ideal for industrial, commercial, and consumer electronics applications requiring compact, efficient inductors with excellent shielding and thermal characteristics. Browse the Surface Mount Inductors category for similar industrial electronic components at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This inductor has an inductance value of 15 μH with a tolerance of ±20%.
It supports a maximum DC current of 9.66 A.
The dimensions are 12.5 mm in length, 8 mm in height, and 12.5 mm in depth.
The maximum operating temperature is rated at 125°C.
It is constructed with a ferrite core, which enhances its magnetic performance.
The maximum self-resonant frequency is 100 kHz.
The DC resistance is 24.7 mΩ, which helps reduce power loss.
It features a surface mount termination style with a 2-pin configuration.
Yes, it is compliant with RoHS standards, ensuring environmental safety.
This inductor is suitable for use in computers, portable devices, and DC-DC converters.
It is packaged in a reel for convenient handling and integration into electronic assemblies.
