STMicroelectronics 1-Element Uni-Directional TVS Diode 600 W, 2-Pin DO-214 SMBJ13A-TR
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 2.45mm |
| Length | 4.6mm |
| Model | SMBJ13A-TR |
| Width | 3.95mm |
| Mount Type | Surface |
| Series | SMBJ |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 27.2V |
| Diode Configuration | Single |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 14.4V |
| Maximum Reverse Stand-off Voltage Vwm | 13V |
| Peak Pulse Power Dissipation Pppm | 600W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 147A |
| Maximum Reverse Leakage Current | 200nA |
Key Features
- This diode features a single uni-directional element configuration.
- The breakdown voltage is rated at a minimum of 14.4 V for reliable voltage clamping.
- It supports a maximum reverse stand-off voltage of 13 V suitable for surface mounting.
- The device can operate within a temperature range from -55°C up to 150°C.
- It has a maximum peak pulse current of 147 A to handle high transient surges.
- Compact dimensions with a length of 4.6 mm, width of 3.95 mm, and height of 2.45 mm.
- The maximum reverse leakage current is 200 nA, ensuring low leakage during normal operation.
- Ideal for protecting sensitive electronics in industrial, automotive, and consumer applications.
Product Description
STMicroelectronics SMBJ13A-TR is a 1-element uni-directional transient voltage suppression (TVS) diode designed to protect electronic circuits from voltage spikes and transients. Rated at a peak pulse power dissipation of 600 W and housed in a compact DO-214 surface-mount package, it provides reliable suppression against transient surges up to 147 A.
The diode features a minimum breakdown voltage of 14.4 V and a maximum reverse stand-off voltage of 13 V, ensuring precise voltage clamping. Operating temperatures range from -55°C to 150°C, making it suitable for harsh industrial and automotive environments.
Its low leakage current of 200 nA at maximum reverse voltage reduces power loss when the device is inactive. The device’s physical size - 4.6 mm length, 3.95 mm width, and 2.45 mm height - allows integration in compact printed circuit boards.
This TVS diode is essential for transient suppression in applications such as power supplies, industrial controls, telecom equipment, and consumer electronics to improve reliability and extend device lifecycle.
This diode features a single uni-directional element configuration. The breakdown voltage is rated at a minimum of 14.4 V for reliable voltage clamping. It supports a maximum reverse stand-off voltage of 13 V suitable for surface mounting.
The device can operate within a temperature range from -55°C up to 150°C. It has a maximum peak pulse current of 147 A to handle high transient surges. Compact dimensions with a length of 4.6 mm, width of 3.95 mm, and height of 2.45 mm.
The maximum reverse leakage current is 200 nA, ensuring low leakage during normal operation. Ideal for protecting sensitive electronics in industrial, automotive, and consumer applications.
For engineers and designers requiring robust transient voltage protection, STMicroelectronics SMBJ13A-TR offers proven performance and surface-mount convenience. Explore more TVS Diode solutions and semiconductor components in EnvMart’s extensive catalog.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The peak pulse power dissipation of this diode is rated at 600 W.
The minimum breakdown voltage for this model is rated at 14.4 V.
The maximum reverse stand-off voltage is 13 V, making it suitable for surface mounting applications.
It can handle a maximum peak pulse current of 147 A.
The dimensions of this model are 4.6 mm in length, 3.95 mm in width, and 2.45 mm in height.
It can operate within a temperature range from -55°C to 150°C.
The maximum reverse leakage current is 200 nA, ensuring low leakage during normal operation.
This diode supports surface mounting, housed in a DO-214 package.
The diode configuration is single, with a uni-directional element.
It is suitable for protecting sensitive electronics in industrial, automotive, and consumer applications.
The clamping voltage (VC) is rated at 27.2 V.
The test current (It) is specified at 1 mA.
