STMicroelectronics Uni-Directional TVS Diode, 1-Element, 5000 W, 2-Pin R-6, 56 V Maximum Reverse Stand-off Voltage BZW50-56

Free Delivery in India | Lowest Global Shipping Charges

STMicroelectronics Uni-Directional TVS Diode, 1-Element, 5000 W, 2-Pin R-6, 56 V Maximum Reverse Stand-off Voltage BZW50-56

Name: STMicroelectronics Uni-Directional TVS Diode, 1-Element, 5000 W, 2-Pin R-6, 56 V Maximum Reverse Stand-off Voltage BZW50-56
Brand: STMicroelectronics
SKU: 219257
Price: 2.59 USD
Availability: InStock



Category TVS Diode Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Diameter	9.1mm
Brand	STMicroelectronics
Height	9.1mm
Length	9.1mm
Model	BZW50-56
Width	9.1mm
Mount Type	Through Hole
Series	BZW50
Maximum Operating Temperature	175°C
Package Type	R-6
Minimum Operating Temperature	-65°C
Standards/Approvals	UL Recognised
Pin Count	2
Number of Elements per Chip	1
Clamping Voltage VC	129V
Diode Configuration	Single
Direction Type	Uni-Directional
Minimum Breakdown Voltage Vbr	62.2V
Maximum Reverse Stand-off Voltage Vwm	56V
Peak Pulse Power Dissipation Pppm	5000W
Test Current It	1mA
Maximum Peak Pulse Current Ippm	465A
Maximum Reverse Leakage Current	5μA

Key Features

The diode configuration is single and supports uni-directional operation.
It features a maximum reverse stand-off voltage of 56 V for reliable circuit protection.
The package type is R-6 with 2 pins for through-hole mounting.
Capable of handling a peak pulse current of 465 A and a clamping voltage of 129 V.
Operates safely in temperatures ranging from -65°C to 175°C.
The diode has dimensions of 9.1 mm in diameter, height, length, and width ensuring compact installation.
It is UL Recognised and suitable for industrial and commercial electronic protection applications.
The maximum reverse leakage current is 5 μA guaranteeing minimal leakage in standby conditions.

Product Description

STMicroelectronics BZW50-56 is a uni-directional transient voltage suppressor (TVS) diode engineered to protect sensitive electronic circuits from voltage spikes and transients. This 1-element diode has a peak pulse power dissipation rating of 5000 W, making it ideal for safeguarding electronic components against high-energy transient surges.

The device features a single diode configuration with a maximum reverse stand-off voltage of 56 V. It operates with a clamping voltage of 129 V and can withstand peak pulse currents up to 465 A. The component utilizes the R-6 package type with two pins designed for through-hole mounting, ensuring easy integration into printed circuit boards.

Operational temperature range extends from -65°C to 175°C, certifying its reliability in harsh environments. Its compact physical dimensions of 9.1 mm in height, length, width, and diameter provide versatility in space-constrained assemblies.

This TVS diode is UL Recognised, demonstrating compliance with industrial standards. The maximum reverse leakage current of 5 μA further establishes its efficiency by minimizing power loss when idle. Its robust performance finds applications in industrial electronics, power supply protection, telecommunications, and automotive circuits, helping prevent damage from electrostatic discharges and voltage transients.

The diode configuration is single and uni-directional for precise transient voltage suppression. Supports through-hole mount with a 2-pin R-6 package for easy PCB integration. Peak pulse power dissipation of 5000 W protects against high energy surges.

Wide operating temperature range from -65°C to 175°C ensures durability in adverse conditions. Compact diode dimensions (9.1 mm) allow use in space-sensitive designs. UL Recognised for compliance with stringent safety and quality standards.

Low maximum reverse leakage current of 5 μA reduces power consumption during standby. Suitable for transient voltage protection in industrial, commercial, and automotive electronics. Explore more components in the TVS Diode category at EnvMart for reliable electronic protection solutions.
