TE Connectivity TERMINYL Insulated Ring Terminal, M5 Stud Size, 8 AWG Wire Size, Nylon Insulation, Red, Model 324043
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Colour | Red |
| THICKNESS | 0.79mm |
| Model | 324043 |
| Insulation | Insulated |
| Overall Length | 35.61mm |
| Contact Material | Copper |
| Series | TERMINYL |
| Maximum Operating Temperature | 105°C |
| Insulation Material | Nylon |
| Standards/Approvals | RoHS |
| Contact Plating | Tin |
| Minimum Wire Size mm² | 6.6mm² |
| Maximum Wire Size mm² | 10.5mm² |
| Minimum Wire Size AWG | 8AWG |
| Outer Ring Diameter | 10.95mm |
| Inner Ring Diameter | 5mm |
| Stud Size | M5 |
Key Features
- Constructed from high grade copper for optimal conductivity.
- Tin plating ensures corrosion resistance and durability.
- Insulated with color-coded nylon for dielectric strength and safety.
- Designed to withstand vibrations, shock, and temperatures up to 105°C.
- Overall length of 35.61 mm for easy installation.
- Outer ring diameter measures 10.95 mm with a 5 mm inner ring diameter.
- Thickness of 0.79 mm provides mechanical stability.
- Compliant with RoHS standards ensuring environmental safety.
Product Description
TE Connectivity 324043 TERMINYL insulated ring terminal is engineered for use with 8 AWG wire sizes, featuring an M5 stud size and red nylon insulation for high dielectric strength and safety.
Manufactured from high conductivity copper material and tin-plated, this Ring Terminal offers excellent resistance to corrosion. It is designed to endure extreme vibration, shock, and temperatures up to 105°C, making it reliable for demanding industrial, electrical, and automotive applications.
The TERMINYL series uses molded nylon insulation with color coding to facilitate easy wire insertion and ensures insulation support. The funnel entry design improves wire crimping consistency.
Physical dimensions include an outer ring diameter of 10.95 mm, inner ring diameter of 5 mm, thickness of 0.79 mm, and an overall length of 35.61 mm, allowing compatibility with a range of equipment and wiring setups.
High grade copper contact material provides maximum conductivity. Tin plating protects contact surfaces from oxidation. The nylon insulation increases dielectric strength and safety. Designed to meet RoHS environmental standards.
Suitable for use in electronics, power connectors, automotive wiring, and industrial machinery applications. Packaging and delivery units are prepared for efficient installation, supplied ready for immediate use in electrical assemblies.
Explore more options and technical components in the Electronics & Electricals category at EnvMart to enhance your projects with quality products from trusted brands.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating temperature for this insulated ring terminal is 105°C.
This model is designed for use with 8 AWG wire sizes, accommodating a minimum wire size of 6.6 mm² and a maximum wire size of 10.5 mm².
The outer ring diameter measures 10.95 mm, while the inner ring diameter is 5 mm.
The contact material used in this terminal is high-grade copper, which provides optimal conductivity.
It features nylon insulation, which is color-coded for dielectric strength and safety.
Yes, this terminal is compliant with RoHS standards, ensuring environmental safety.
The thickness of this ring terminal is 0.79 mm, providing mechanical stability.
The overall length of this insulated ring terminal is 35.61 mm, facilitating easy installation.
The stud size for this terminal is M5.
The contact surfaces of this terminal are tin-plated, which helps to protect against corrosion.
This insulated ring terminal is suitable for use in electronics, power connectors, automotive wiring, and industrial machinery applications.
The funnel entry design of this terminal improves wire crimping consistency, ensuring reliable connections.
