TE Connectivity Mini-Universal MATE-N-LOK Series Right Angle Through Hole PCB Header, 2 Contacts, 4.14 mm Pitch 1-770966-1

Free Delivery in India | Lowest Global Shipping Charges

TE Connectivity Mini-Universal MATE-N-LOK Series Right Angle Through Hole PCB Header, 2 Contacts, 4.14 mm Pitch 1-770966-1

Name: TE Connectivity Mini-Universal MATE-N-LOK Series Right Angle Through Hole PCB Header, 2 Contacts, 4.14 mm Pitch 1-770966-1
Brand: TE Connectivity
SKU: 217824
Price: 5.31 USD
Availability: InStock



Category PCB Connectors & Wire Housings Brand TE Connectivity Condition New

Specifications

Country of Origin	India
Voltage	600V
Brand	TE Connectivity
Orientation	Right Angle
Current	9.5A
Mount Type	Through Hole
Housing Material	Nylon
Contact Material	Brass
Series	Mini-Universal MATE-N-LOK
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	4.14mm
Contact Plating	Gold
Number of Contacts	2
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Tail Pin Length	3.69mm

Key Features

Features a right angle orientation for efficient PCB layout.
Made with a shrouded nylon housing for durability and secure mating.
Brass contacts plated with gold provide reliable conductivity.
Supports a continuous current rating of 9.5 amperes.
Operates safely up to 600 volts maximum voltage.
Includes a positive locking latch mechanism for secure connections.
Through hole mount type ensures sturdy PCB attachment.
Tail pin length of 3.69 mm for effective soldering.

Product Description

TE Connectivity 1-770966-1 Mini-Universal MATE-N-LOK Series Right Angle Through Hole PCB Header with 2 contacts, 4.14 mm pitch, and rated for 600 volts and 9.5 amperes current. This connector is engineered for reliable wire-to-board applications in various industrial and electronic sectors.

The header features a shrouded housing made from UL94V-0 nylon material, providing excellent electrical insulation and flame retardancy. Gold-plated brass contacts ensure low resistance and corrosion resistance, enhancing signal integrity and durability over time.

Its right angle orientation and through hole mount allow for efficient PCB layout and secure mechanical stability. The positive locking latch mechanism ensures a secure mating connection, preventing accidental disconnections during operational use. The board lock feature facilitates robust retention on printed circuit boards.

Operating temperature range from -55°C to 105°C supports performance in harsh environments, suitable for industrial, manufacturing, automotive, and electronic equipment assembly use cases. The connector complies with standard electrical safety parameters without specific certification approvals.

Mini-Universal MATE-N-LOK series connectors offer design flexibility for engineers requiring compact, reliable connectors for wire-to-board interfacing in demanding applications. TE Connectivity's solutions ensure high quality and performance in electronic assembly lines.

Right angle shrouded PCB header for wire-to-board connection. 2 gold-plated brass contacts with 4.14 mm pitch spacing. 600V rated, supporting up to 9.5A current load. Durable UL94V-0 nylon housing with positive latch and board lock.

Through hole solder termination for strong PCB mounting. Wide operating temperature range from -55°C to 105°C. Ideal for industrial, electronic component, and manufacturing applications.
