TE Connectivity Mini-Universal MATE-N-LOK Series Right Angle Through Hole PCB Header, 2 Contacts, 4.14 mm Pitch 1-770966-1

Free Delivery in India | Lowest Global Shipping Charges

TE Connectivity Mini-Universal MATE-N-LOK Series Right Angle Through Hole PCB Header, 2 Contacts, 4.14 mm Pitch 1-770966-1

Name: TE Connectivity Mini-Universal MATE-N-LOK Series Right Angle Through Hole PCB Header, 2 Contacts, 4.14 mm Pitch 1-770966-1
Brand: TE Connectivity
SKU: 217822
Price: 6.27 USD
Availability: InStock



Category PCB Connectors & Wire Housings Brand TE Connectivity Condition New

Specifications

Country of Origin	India
Voltage	600V
Brand	TE Connectivity
Orientation	Right Angle
Current	9.5A
Mount Type	Through Hole
Housing Material	Nylon
Contact Material	Brass
Series	Mini-Universal MATE-N-LOK
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	4.14mm
Contact Plating	Gold
Number of Contacts	2
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Tail Pin Length	3.69mm

Key Features

Mini-Universal MATE-N-LOK series for reliable wire-to-board connections.
Right angle orientation facilitates PCB mounting and board space optimization.
Housing made from durable UL94V-0 nylon ensuring high insulation and safety.
Brass contacts with gold plating provide excellent conductivity and corrosion resistance.
Rated for operating temperatures from -55°C to 105°C for broad application environments.
Solder termination style with tail pin length of 3.69 mm for secure PCB attachment.
2 contacts with a pitch of 4.14 mm support moderate current load up to 9.5 A.
Incorporates positive locking latches and board locks for secure mating and retention.

Product Description

TE Connectivity 1-770966-1 Mini-Universal MATE-N-LOK Series Right Angle Through Hole PCB Header is designed for dependable wire-to-board electronic connections. It features 2 gold-plated brass contacts housed in a white UL94V-0 nylon shrouded housing, providing enhanced insulation and durability. The connector is optimized for industrial and electronic applications with a 4.14 mm pitch, rated current of 9.5 A, and voltage of 600 V.

This right angle header supports solder termination with a 3.69 mm tail pin length, facilitating secure and reliable mounting onto printed circuit boards. The housing incorporates positive locking latches and board locks that ensure secure mating and prevent connector disengagement during operation.

Operating temperature ranges from -55°C to 105°C, suitable for various harsh conditions encountered in electronics manufacturing, power supplies, telecommunications, and automation equipment. The nylon material assures flame resistance and mechanical robustness for long-lasting performance.

The connector system is part of the Mini-Universal MATE-N-LOK series, known for versatility in wire-to-board interconnection solutions. Ideal for automotive, industrial control, and general electronics applications requiring compact, reliable PCB headers.

Mini-Universal MATE-N-LOK series connector. Right angle through hole PCB header with 2 contacts. 4.14 mm contact pitch with gold-plated brass contacts. UL94V-0 Nylon shrouded housing with positive locking latches. Rated 600 V, 9.5 A current, temperature range -55°C to 105°C.

Solder termination with 3.69 mm tail pin length. Secure board locks for reliable PCB retention. Suitable for industrial, power, and electronic applications. Explore the TE Connectivity Mini-Universal MATE-N-LOK series and related PCB headers and connectors at EnvMart for your electronic assembly and design needs.
