Preci-Dip Straight Surface PCB Socket, 4-Contact, 2 Row, 2.54 mm Pitch, 12A, 150V, Black Glass Filled 410-87-204-01-640101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Straight |
| Current | 12A |
| Mount Type | Surface |
| Housing Material | Black Glass Filled Polyester |
| Contact Material | Beryllium Copper Alloy |
| Series | 410 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold Flash |
| Number of Contacts | 4 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- The socket supports a current rating of 12A and a voltage rating of 150V.
- Housing is made from black glass filled polyester ensuring durability and insulation.
- Contacts are female, constructed from beryllium copper alloy with gold flash plating for superior conductivity and corrosion resistance.
- Designed for operating temperatures from -55°C to 125°C, suitable for harsh environments.
- Offers a straight orientation with a 2.54 mm row pitch suitable for IC sockets with 0.47 mm pin diameter.
- Mount type is surface mount with solder termination ensuring stable mechanical and electrical connection.
- Connector system is board-to-board type for stacking or linking PCBs.
- Complies with UL 94V-0 flammability standard enhancing safety in electronic applications.
Product Description
Preci-Dip 410-87-204-01-640101 is a high-quality straight surface PCB socket designed for secure board-to-board connections. Featuring 4 female contacts arranged in 2 rows with a pitch of 2.54 mm, this socket supports a current capacity of 12A and voltage rating of 150V, making it ideal for various industrial and electronic applications.
The socket housing is crafted from black glass filled polyester which provides excellent mechanical strength and electrical insulation. The contact material consists of beryllium copper alloy with a gold flash plating which ensures reliable conductivity and resistance to corrosion over extended use.
Suitable for operating in a wide temperature range from -55°C up to 125°C, this PCB Socket performs well in demanding environments such as industrial machinery, manufacturing systems, and electronic assemblies requiring durability and thermal stability.
The mounting type is surface mount with a solder termination finish for a robust and lasting connection. The socket accommodates pins of 0.47 mm diameter and features a standoff style through-hole design with pin length of 3.2 mm for mechanical stability.
This product complies with UL 94V-0 flammability standards ensuring safety and reliability in electronic equipment. The socket is ideal for use in industrial electronics, automation control systems, telecommunications, and other commercial PCB applications.
Provides a secure and precise board-to-board connection with easy solder mount integration. Stable electrical performance with gold flash plated contacts and beryllium copper alloy material. Reliable operation across a wide temperature range for various environmental conditions.
Swiss manufacturing quality guarantees high precision and product reliability. Explore our comprehensive range of electronic components and PCB accessories for your industrial and commercial projects with confidence at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB socket supports a current rating of 12A and a voltage rating of 150V.
It is designed to operate within a temperature range of -55°C to 125°C, making it suitable for harsh environments.
The housing is made from black glass filled polyester, while the contacts are constructed from beryllium copper alloy with gold flash plating.
This model features a surface mount design with solder termination, ensuring a stable mechanical and electrical connection.
The socket has a pitch of 2.54 mm and features 4 female contacts arranged in 2 rows.
It utilizes a board-to-board connector system, allowing for secure stacking or linking of PCBs.
This PCB socket accommodates pins with a diameter of 0.47 mm.
Yes, it complies with the UL 94V-0 flammability standard, enhancing safety in electronic applications.
The pins have a length of 3.2 mm, providing mechanical stability for the connection.
This PCB socket is manufactured in Switzerland.
It is suitable for various applications in industrial electronics, automation control systems, and telecommunications.
The contacts are gold flash plated, which ensures reliable conductivity and resistance to corrosion.
